TOP AND CABINET PARTS
2
For Model: WTW6400SW2
(White)
W10119754
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10106470 Use & Care Guide
W10026571 Tech Sheet
W10106480 Quick Start Guide
8577781 Wiring Diagram
W10107030 Energy Guide
2 8565311 Top
3 W10114656 Frame Assembly,
Cabinet Top
(Includes
Items 31 & 51)
4 8576784 Sound Absorber,
Cabinet
5 8566156 Cabinet
6 8566090 Panel, Rear
7 8543781 Retainer, Drain
Hose Storage
8 8578225 Sound Absorber,
Cabinet
9 W10111536 Ball,
Suspension (4)
10 8564009 Damper Assembly,
Tub Suspension
(Set Of 4−Includes
Items 48 & 52)
11 1157158 Screw, 8−18 x 3/8
12 W10042120 Locator, Top (2)
13 355274 Screw, Lid
Hinge
Mounting (4)
14 8576780 Hinge Arm, Lid (2)
15 Hinge, Spring
Assembly
8563962 (Left)
8563963 (Right)
16 8563785 Lock, Top−
Front (2)
17 W10052730 Bearing, Lid
Hinge (2)
18 8577353 Lid−Inner
(Includes Item 47)
19 8572891 Lid
20 8578826 Foot Assembly,
Leveling (4)
21 W10059150 Dispenser,
Fabric Softener
22 8566210 Bezel, Fabric
Softener Dispenser
23 W10059160 Dispenser, Bleach
24
8566211 Bezel, Bleach
Dispenser
25 8564976 Dispenser,
Detergent
26 8564979 Bezel, Detergent
Dispenser
27 W10106990 Nozzle Assembly,
Fresh Water
28 371503 Clamp, Hose
29 W10059230 Lock Assembly, Lid
30 8572019 Bezel, Lid Lock
31 8564458 Absorber, Impact
32 8564456 Hinge, Top (2)
33 18849 Pad, Top Hinge (2)
34 343641 Screw,
10−16 x 1/2 (2)
35 8563941 Cover, Harness
36 693995 Screw, 8−18 x 3/8
37 8543784 Bracket,
Drain Hose
38 W10076920 Screw (2)
39
8281136 Screw, 10−16 x 3/4
40 8576476 Spacer, Rear
(Cabinet/Top)
41 370451 Clamp, Hose
42 371503 Clamp, Hose
43 3400061 Screw,
10−16 x 9/16
44 90016 Clip, Harness (5)
45 8281736 Wire,
Ground Jumper
46 3400076 Screw, 10−32 x 5/8
47 W10076780 Bumper, Lid (2)
48
8577896 Washer, Suspension
Umbrella (4)
49 3390647 Screw, 8−18 x 1/2
50 21097 Pad,
Lid Hinge (2)
51 8578386 Shield, Wire
Harness
52 8564017 Cup,
Suspension (4)
