- ILLUSTRATED PARTS MANUAL
- KEY TO ABBREVIATIONS USED IN THIS MANUAL
- ILLUSTRATED PARTS LIST
- TRACTOR DECALS
- 1 7802 RH Fender Body, RH Side near Seat 1 1
- 2 5856 Made in USA Body, Spring Bracket 1 1
- 3 5803 Walker Manufacturing Logo Body 1 1
- 4 5813-1 Powerfil® 7.0 / 9.5 Bushel Catcher, Front 1 0
- 5 5801 GHS 7.0 / 9.5 Bushel Catcher (one on each side) 2 0
- 6 5800 Walker Mower (4 x 7-1/2) Utility Bed (one on each side) 0 2
- 7 5806 Blade Clutch Body, RH Side 1 1
- 8 5804 Blower Blade Warning Body near Body Chute 1 0
- 9 7818 Warning, Read Manual Body 1 1
- 10 5868 Danger, Pinch Point 7.0 / 9.5 Bushel Catcher Mounting Frame Assembly 2 0
- 11 7809 Parking Brake Body, RH Side below Seat 1 1
- 12 8400-6 Danger, Body Latch Body 1 1
- 13 7819 Throttle Body, LH Side 1 1
- 14 NS Sealed Reservoir Hydrostatic Drives (one on each) 2 2
- 15 5810-1 Axle Oil Level Gear Axle Drive Assemblies (one on each) 2 2
- 16 5819 Blower Maintenance Blower Housing 1 0
- 17 6875 PTO Alignment Arrow Universal Joint Tube Assembly 1 1
- 18 7827 Oil Level Jackshaft Support 1 1
- 19 5874 Push to Release 7.0 / 9.5 Bushel Catcher Safety Latch 1 0
- 20 8825 Front Body Closure Rear Cross Member, Body 1 1
- 21 5869 Removable Screen 7.0 / 9.5 Bushel Catcher Removable Screen 1 0
- 22 NS Caution (19426-87881 Kubota) Radiator 1 1
- 23 NS Caution (19426-87903 Kubota) Air Cleaner Cover 1 1
- 24 7633 Power Dump Switch Body 1 0
- 25 8555 Tail Wheel Lock FSC Lever Assembly - Switch Mount Bracket 1 1
- 26 8654 Power Deck Lift Body, RH Side 1 1
- TRACTOR DECALS
- BODY / CHASSIS ASSEMBLY (GHS MODELS)
- 1 5103 Seat 1
- 2 7203 Seat Spring Plate 1
- 3 7223 Compression Spring (1/2 x 1) 2
- 4 7845 Rubber Bumper (1.375 OD x .63) 2
- 5 7846 Washer (3/8 ID x 1-1/4 OD x 1/8) 2
- 6 7204 Shoulder Bolt, Seat Mount 2
- 7 7440-5 Shock Mount (1-1/4 x 3/4) 2
- 8 NS Recovery Tank Mount 1
- 9 7047-5 Mount Plate 1
- 10 7516-7 7.0 / 9.5 Rear Bumper 1
- 11 7516-5 Catcher Pivot Bushing 2
- 12 5162 Roller Wheel (5" Rubber) 2
- 13 7517-2 Catcher Pivot Plate 2
- 14 5832 Cable Clamp (1/2) 2
- 15 NS Body ID Plate 1
- 16 5845 Rubber Bumper (1.50 OD x 1.25) 4
- 17 7422 Panel Guard 1
- 18 5989-4 Dome Plug (3/8) 4
- 19 5989-3 Dome Plug (5/16) 2
- 20 7146 13mm Ball Stud 2
- 21 7844 Rubber Bumper (1.25 OD x .25) 1
- 22 7147 Spring Clip 2
- 23 7145 Gas Spring Assembly 1
- 24 7222 Extension Spring (1/4 x 3) 1
- 25 7383-2 Body Latch Hook 1
- 26 7854 Plastic Tip, Red 1
- 27 5989-9 Dome Plug (1/4) 8
- 28 7100 Front Body 1
- 29 5180 Edge Molding, Lever Opening 2
- 30 5989-55 Dome Plug (1/2) 1
- 31 5989-5 Dome Plug (7/16) 1
- 32 5847 Plastic Tip 1
- 33 5744-20 Spring Arm, Tilt-Up Latch 1
- 34 5744-10 Spring Pivot Bushing 1
- 35 5744-15 Compression Spring (3/8 x 5/8) 1
- 36 5744-13 Mount Angle, LH 1
- 37 5744-12 Hook, Tilt-Up Latch 1
- 38 5744-14 Mount Angle, RH 1
- 39 5267-1 Retainer Collar (1") 1
- 40 5270-1 Pivot Bearing 2
- 41 7420 Tail Wheel Fork 1
- 42 5830-3 Grease Fitting (45 Degree) 2
- 43 8039 Nut, Tail Wheel Axle 2
- 44 8037-1 Seal, Outer (1-3/4 x 1-1/8) 2
- 45 8038-1 Spacer, Tail Wheel Axle 2
- 46 8037 Bearing Cone (3/4 ID) 4
- 47 8037-2 Bearing Race 4
- 48 8035 Tail Wheel & Tire (13 x 5.00-6) 2
- 49 8768-2 Seal, Reverse Lip 2
- 50 8038 Tail Wheel Axle (3/4 x 10-3/8) 1
- 51 7070 Wheel & Tire (18 x 9.5-8) 2
- 52 7300-5 Chassis Frame 1
- BODY / CHASSIS ASSEMBLY (GHS MODELS)
- REAR BODY ASSEMBLY (GHS MODELS)
- REAR BODY ASSEMBLY (GHS MODELS)
- BODY ASSEMBLY (SD MODELS)
- 1 8650-10 Bed Liner (21.5 x 27.5) 1
- 2 7650-3 Utility Bed (Includes Item # 1) 1
- 3 7190-2 Insulation Foam Pad, RH 1
- 4 7190-1 Insulation Foam Pad, LH 1
- 5 7153-3 Cover Plate 1
- 6 5845 Rubber Bumper (1.50 x 1.25) 1
- 7 7145 Gas Spring Assembly 1
- 8 7147 Spring Clip 2
- 9 7146 13mm Ball Stud 2
- 10 7521-5 Rear Bumper 1
- 11 NS Recovery Tank Mount 1
- 12 7047-5 Mount Plate 1
- 13 5832 Cable Clamp (1/2) 2
- 14 5162 Roller Wheel (5" Rubber) 2
- 15 7105-5 Rear Body Panel 1
- BODY ASSEMBLY (SD MODELS)
- MAIN COMPONENT POWER TRANSMISSION (GHS MODELS)
- 1 5830 Grease Fitting 4
- 2 5229 Extension Spring (1/2 x 2-1/4) 1
- 3 7243 Clutch Idler Pulley 1
- 4 7368-2 PTO Belt Tightener (1.75 TAB) 1
- 5 7201-3 DU Bearing 6
- 6 7201-6 Inner Race (3-5/8) 1
- 7 7303-9 Clutch Actuator Block 1
- 8 7226 Compression Spring (3/4 x 2-1/2) 1
- 9 7380 Knuckle Joint 1
- 10 5830-3 Grease Fitting (45 Degree) 1
- 11 7303-7 Clutch Actuator Rod 1
- 12 7378 Pivot Bearing (7/16 x 9/16) 1
- 13 7358 Clutch Lever 1
- 14 7860 Handle Grip 1
- 15 7050-1 Dipstick, Gearbox 1
- 16 7377-1 Brake Band Guide 1
- 17 7050-11 PTO Gearbox / Flange Pulley 1
- 18 7248 Ground Drive Belt, Micro-V 1
- 19 7275-16 Universal Joint Tube Assembly / Spline 1
- 20 7303-2 Brake Band (13-5/8) 1
- 21 7236-1 PTO Drive Pulley (4-1/2 / 3V) 1
- 22 7237-30 Engine Pulley (Flywheel Mount) 1
- 23 7230 Engine PTO Belt 1
- 24 6231 Drive Belt (3VX355) 1
- 25 7240-3 Jackshaft Drive Pulley (4.15/3V) 1
- 26 5268 Bearing with Collar (3/4) 2
- 27 7273 Jackshaft (3/4 x 8-7/8) 1
- 28 7393-7 Hydro Jackshaft Mount 1
- 29 5841 Retainer Washer (3/8 x 1-1/4) 1
- 30 7201-4 Inner Race (1-1/2) 2
- 31 7349-50 Idler Arm 1
- 32 7349-2 Extension Spring (3/4 x 4) 1
- 33 6325-3 Spacer Bushing (9/16) 1
- 34 5245 Idler Pulley (3") 1
- 35 7241-2 Transmission Drive Pulley (3-1/4/MV) 1
- 36 7245-1 Idler Pulley (3/8 Groove) 1
- 37 7374 Ground Drive Release Arm 1
- 38 7390 Idler Arm Guide 1
- 39 7406-1 Handle Grip, Red 1
- 40 7376 Handle, Ground Drive Release 1
- 41 5221 Extension Spring (3/4 x 4) 1
- 42 7854 Plastic Tip, Red 1
- 43 7375 Spring Arm, Ground Drive Idler Release 1
- 44 7225 Compression Spring (7/16 x 1/2) 1
- MAIN COMPONENT POWER TRANSMISSION (GHS MODELS)
- MAIN COMPONENT POWER TRANSMISSION (SD MODELS)
- 1 5830 Grease Fitting 4
- 2 5229 Extension Spring (1/2 x 2-1/4) 1
- 3 7243 Clutch Idler Pulley 1
- 4 7368-2 PTO Belt Tightener (1.75 TAB) 1
- 5 7201-3 DU Bearing 6
- 6 7201-6 Inner Race (3-5/8) 1
- 7 7303-9 Clutch Actuator Block 1
- 8 7226 Compression Spring (3/4 x 2-1/2) 1
- 9 7380 Knuckle Joint 1
- 10 5830-3 Grease Fitting (45 Degree) 1
- 11 7303-7 Clutch Actuator Rod 1
- 12 7378 Pivot Bearing (7/16 x 9/16) 1
- 13 7358 Clutch Lever 1
- 14 7860 Handle Grip 1
- 15 7050-1 Dipstick, Gearbox 1
- 16 7377-1 Brake Band Guide 1
- 17 7050-11 PTO Gearbox / Flange Pulley 1
- 18 7248 Ground Drive Belt, Micro-V 1
- 19 7275-16 Universal Joint Tube Assembly / Spline 1
- 20 7303-2 Brake Band (13-5/8) 1
- 21 7236-1 PTO Drive Pulley (4-1/2 / 3V) 1
- 22 7237-30 Engine Pulley (Flywheel Mount) 1
- 23 7230 Engine PTO Belt 1
- 24 6231 Drive Belt (3VX355) 1
- 25 7240-3 Jackshaft Drive Pulley (4.15/3V) 1
- 26 5268 Bearing with Collar (3/4) 2
- 27 7273 Jackshaft (3/4 x 8-7/8) 1
- 28 7393-7 Hydro Jackshaft Mount 1
- 29 5841 Retainer Washer (3/8 x 1-1/4) 1
- 30 7201-4 Inner Race (1-1/2) 2
- 31 7349-50 Idler Arm 1
- 32 7349-2 Extension Spring (3/4 x 4) 1
- 33 6325-3 Spacer Bushing (9/16) 1
- 34 5245 Idler Pulley (3") 1
- 35 7241-2 Transmission Drive Pulley (3-1/4/MV) 1
- 36 7245-1 Idler Pulley (3/8 Groove) 1
- 37 7374 Ground Drive Release Arm 1
- 38 7390 Idler Arm Guide 1
- 39 7406-1 Handle Grip, Red 1
- 40 7376 Handle, Ground Drive Release 1
- 41 5221 Extension Spring (3/4 x 4) 1
- 42 7854 Plastic Tip, Red 1
- 43 7375 Spring Arm, Ground Drive Idler Release 1
- 44 7225 Compression Spring (7/16 x 1/2) 1
- MAIN COMPONENT POWER TRANSMISSION (SD MODELS)
- ENGINE GROUP
- 1 7929 Actuating Solenoid 1
- 2 7343 Solenoid Mount 1
- 3 7305 Solenoid Linkage Rod 1
- 4 NS Kubota Diesel Engine 1
- 5 7341 Throttle Cable Mount Bracket 1
- 6 5083-2 Tank Tube Elbow 1
- 7 5879-3 Hose Clamp (1/2) 2
- 8 7015-14 Hose (1/4 x 16-1/2) 1
- 9 5975-3 Cable Tie (50# x 7") 1
- 10 7833 Cable Clamp (7/8 x 1/4) 2
- 11 7015-12 Hose (3/16 x 32) 1
- 12 5879-2 Hose Clamp, Silver (7/16) 2
- 13 7840-2 Hose Clamp (1/4 to 5/8) 6
- 14 7015-16 Hose (5/16 x 14-1/2) 1
- 15 NS Fuel Filter (19204-43010 Kubota) 1
- 16 7015-17 Hose (5/16 x 25-1/2) 1
- 17 7021 Fuel Filter (15231-43560 Kubota) 1
- 18 7389 Splash Guard 1
- 19 7048 Trash Guard 1
- 20 7015-15 Hose (5/16 x 17-1/2) 1
- 21 NS Fuel Pump (12691-52031 Kubota) 1
- 22 7020 Fuel Filter (In-Line) 1
- 23 8046-8 Fuel Tank, 5 Gallon, Diesel 1
- 24 5082-2 Fuel Cap Seal *
- 25 7082 Fuel Tank Cap, Diesel *
- 26 5020-2 Fuel Filter, In Tank 1
- 27 5086 Fuel Line (In Tank P/U) 1
- 28 5083-1 Bushing, Rubber *
- 29 7046-1 Fuel Return Tube 1
- ENGINE GROUP
- AIR INTAKE AND EXHAUST GROUP
- 1 7026-2 Remote Precleaner (Includes Item # 5) 1
- 2 7440 Shock Mount (1.0 OD x .75) 3
- 3 7028-20 Rear Precleaner Mount 1
- 4 7027 Elbow, Precleaner 1
- 5 7840 Hose Clamp (1-5/16 to 2-1/4) 3
- 6 5088-10 Air Cleaner Assembly *
- 7 5088-1 Air Cleaner Band 1
- 8 5090-3 Safety Filter Insert 1
- 9 5090-1 Air Cleaner Cartridge 1
- 10 5088-5 Air Cleaner Draw Latch 2
- 11 5088-11 Air Cleaner Cap 1
- 12 5090-2 Vacuator Valve 1
- 13 6029 Hose Clamp (2-1/2) 1
- 14 7016 Air Intake Hose 1
- 15 5091-10 Air Flow Indicator & Nipple 1
- 16 7031 Tube Support Arm 1
- 17 7028-3 Precleaner Tube, SD 1
- 18 7028-2 Precleaner Tube, GHS 1
- 19 7437-1 Exhaust Manifold Shield 1
- 20 NS Spring Washer (04512-50080 Kubota) 4
- 21 7437-6 Engine Brace 1
- 22 NS Muffler (15262-12110 Kubota) 1
- 23 NS Muffler Gasket (15371-12370 Kubota) 2
- 24 7034 Spacer, Muffler 1
- 25 7354 Motor Mount 2
- 26 7306-15 Water Temperature Sender 1
- 27 7306-12 Temperature Sender Adapter 1
- 28 7306-13 Oil Pressure Switch 1
- 29 7023 Oil Filter (15841-32429 Kubota) 1
- 30 7047-2 Manifold Heat Shield 1
- 31 7013-2 Tail Pipe 1
- AIR INTAKE AND EXHAUST GROUP
- RADIATOR GROUP
- 1 7840-4 Hose Clamp (3/4 to 1-1/2) 1
- 2 7017-3 Upper Radiator Hose 1
- 3 7840-3 Hose Clamp (1/2 to 1-1/4) 3
- 4 7427-21 Fan Mount Tab, LH 2
- 5 7429-6 Radiator Cooling Fan 1
- 6 7427-5 Radiator Fan Shroud 1
- 7 NS Recovery Tank Hose Clamp 2
- 8 7015-6 Recovery Tank Hose 1
- 9 NS Coolant Recovery Tank and Hose 1
- 10 5975-3 Cable Tie (50# x 7") 2
- 11 7427 Radiator 1
- 12 7431-1 Radiator Channel Seal (1/4 x 1/2 x 13.5) 2
- 13 7435 Radiator Brace 1
- 14 7432 Shock Mount (1.00 OD x .75) 1
- 15 7425 Radiator Screen 1
- 16 7426 Screen Channel 2
- 17 7430 Radiator Guard 1
- 18 5841 Retainer Washer (3/8 x 1-1/4) 2
- 19 7434 Rubber Washer (3/8 x 1-1/4 x 1/4) 4
- 20 7427-7 Debris Shield, Shroud 1
- 21 7427-22 Fan Mount Tab, RH 2
- 22 7017-2 Lower Radiator Hose 1
- RADIATOR GROUP
- HYDROSTATIC GROUND DRIVE ASSEMBLIES
- 1 5028-3 Transmission Lockout Assembly *
- 2 5847 Plastic Tip 2
- 3 5057 Lockout Cam 2
- 4 5028-5 Lockout Lever 2
- 5 5027-5 Lockout Mount 2
- 6 6209-1 Bridge Assembly 1
- 7 5832 Cable Clamp (1/2) 1
- 8 7394-7 Throttle Cable Mount Bracket 1
- 9 6243-2 Hydro Fan, CCW 1
- 10 5025 Hydrostatic Drive, CCW (700-042) 1
- 11 6206-1 Air Vent Valve *
- 12 6200-9 Gear Axle Drive Assembly 2
- 13 6207-12 Pipe Plug (1/4 NPTF) 4
- 14 5126 Cable Retainer 1
- 15 6233-1 Pinion Gear 2
- 16 6234 Spacer, Pinion Gear 2
- 17 6201 O-Ring Seal 2
- 18 7244 Hydro Pulley (3-7/8/MV) 2
- 19 6243-1 Hydro Fan, CW 1
- 20 5026 Hydrostatic Drive, CW (700-041) 1
- 21 6430-10 Outboard Mount, LH 1
- 22 6430-2 Deck Support Arm, LH 1
- 23 5775-2 Hitch Pin (# 6) 2
- 24 6430-1 Deck Support Arm, RH 1
- 25 6430-9 Outboard Mount, RH 1
- 26 5830 Grease Fitting 2
- 27 6840-1 Support Arm Bushing (2-1/16) 2
- 28 5025-5 Input Shaft *
- 29 5025-8 Bearing, Input Shaft *
- 30 5025-7 Snap Ring *
- 31 5025-2 Seal, Input Shaft *
- 32 5022 Reservoir to Casting Gasket *
- 33 5024 Reservoir Cap and Gasket *
- 34 5023 Transmission Reservoir Kit *
- 35 5023-1 Rubber Bladder *
- 36 5025-6 O-Ring & Plug Assembly *
- 37 5025-3 Seal, Control Shaft *
- HYDROSTATIC GROUND DRIVE ASSEMBLIES
- STEERING CONTROL ASSEMBLIES
- 1 6199-10 Transmission Spring Assembly (RH) *
- 2 5552 Ball Joint (1/4-28) 2
- 3 5192-1 Spring Plunger (Male) 2
- 4 5194 Plunger Sleeve 2
- 5 5193 Washer (3/4 x 1 x .085) 2
- 6 6191 Spring Slide (4-3/4) 1
- 7 5195-2 Compression Spring (1 x 6-3/8) 2
- 8 6196 Spring Slide Cap 1
- 9 5197 J-Bolt 1
- 10 5191 Spring Slide (3-5/8) 1
- 11 5199-10 Transmission Spring Assembly (LH) *
- 12 5214-2 Ball Joint (5/16-24) Nylon Lined 2
- 13 5173 FSC Actuator Rod 1
- 14 5172 Bearing, Nylon (.255 ID x .379 OD x .250) 1
- 15 5142-2 FSC Actuator Cam 1
- 16 5830 Grease Fitting 6
- 17 6212 Transmission Control Arm, RH 1
- 18 5141 FSC Friction Washer (1-1/2 x 3/8 x 1/16) 2
- 19 5140-15 FSC Friction Body 1
- 20 5142-7 FSC Key W/Stop 1
- 21 5850-2 Handle Grip, Foam (5-1/2) 2
- 22 5212-2 Transmission Control Arm, LH 1
- 23 5213-2 Control Rod, LH (6") 1
- 24 5223 Extension Spring (1/4 x 5-1/2) 2
- 25 5450 D-Clip 2
- 26 5463 Steering Lever Actuator 2
- 27 5214-1 Bearing (.320 x .438 x .250) 2
- 28 5391-3 Steering Lever Support 1
- 29 5217 Pivot Pin, Steering Lever 1
- 30 5451-3 Steering Lever Assembly, LH / Adjustable 1
- 31 5219 Extension Spring (3/4 x 6-3/4) 1
- 32 5280 Clevis (1/4) 1
- 33 5281-5 Clevis Pin (1/4 x 0.80) 1
- 34 5470-1 Speed Control Stop 1
- 35 5450-3 Steering Lever Assembly, RH / Adjustable 1
- 36 5453-10 Steering Lever Handle / Adjustable 2
- 37 5862 FSC Knob 1
- 38 7170 FSC Lever Assembly 1
- 39 5975-3 Cable Tie (50# x 7") 1
- 40 5213-1 Control Rod, RH (15") 1
- STEERING CONTROL ASSEMBLIES
- THROTTLE CONTROL ASSEMBLIES
- 1 5832 Cable Clamp (1/2) 2
- 2 7220 Throttle Cable 1
- 3 NS 10-32 Jam Nut 2
- 4 5150 Ball Joint (10-32) 2
- 5 5108-7 Control Lock Tab 1
- 6 5108-10 Friction Washer (.125) 1
- 7 5108-1 Control Lever, Throttle 1
- 8 5108-5 Throttle Control Knob, Red 1
- 9 5108-11 Friction Washer (.062) 1
- 10 5108-8 Control Bracket (Diesel) 1
- 11 7108 Control Assembly *
- 12 7112 Throttle Control and Cable Assembly *
- THROTTLE CONTROL ASSEMBLIES
- PARKING BRAKE ASSEMBLY
- 1 7406-1 Handle Grip, Red 1
- 2 7406-8 Parking Brake Lever (4-1/4) 1
- 3 7406-2 Lever Mount 1
- 4 5830 Grease Fitting 1
- 5 7407 Clevis Pin (3/16 x 1/2) 2
- 6 7404 Brake Actuator Arm 2
- 7 7405 Pin, Transmission Lock 2
- 8 7402 Clevis 2
- 9 7408 Compression Spring (1/2 x 3/4) 2
- 10 7415 Rubber Dust Shield (5/8 x 3/8 x 1/32) 2
- 11 5567-3 O-Ring Seal (1/4 x 3/8) 4
- 12 7403 Plunger Bushing, Gear Axle 2
- 13 7404-1 Brake Actuator Mount 2
- 14 7412 Clevis Pin (3/16 x 5/8) 2
- 15 5833 Cable Clamp (1/4) 2
- 16 7410 Brake Control Cable, LH (25.5") 1
- 17 7409 Brake Control Cable, RH (20.5") 1
- 18 7401-3 Cable Mount Bracket 1
- 19 7401-1 Cable Pull Rod 1
- 20 5552 Ball Joint (1/4-28) 1
- PARKING BRAKE ASSEMBLY
- GHS GROUP
- 1 5515-2 Elbow Delivery Spout 1
- 2 5592-13 Backing Plate, Grass-Pak® Switch 1
- 3 5592-12 Mount Plate, Grass-Pak® Switch 1
- 4 5578 Rear Clip, Chute Mount 1
- 5 5577 Side Clip, Chute Mount 2
- 6 7511-1 7.0 Delivery Chute W/Clips 1***
- 7 5578-10 Front Clip, Chute Mount 1
- 8 7530-4 Body Chute (10.5 Blower) 1
- 9 7238-6 Blower Drive Pulley 1
- 10 7234-1 Blower Belt (Micro-V) 1
- 11 7239-1 Blower Pulley (Micro-V) 1
- 12 7364-2 Torsion Spring 1
- 13 7201-3 DU Bearing 2
- 14 5830-3 Grease Fitting (45 Deg.) 1
- 15 7364-1 Blower Belt Tightener Arm 1
- 16 7201-4 Inner Race (1-1/2) 1
- 17 5841 Retainer Washer (3/8 x 1-1/4) 1
- 18 5245 Idler Pulley (3") 1
- 19 5268 Bearing W/Collar (3/4) 2
- 20 7542 Blower Assembly (10.5") 1
- 21 7542-2 Back Plate (10.5 Blower) 1
- 22 7545-2 Blower Output Shaft (10.5 Blower) 1
- 23 7545 Blower Wheel (10.5") 1
- 24 7542-4 Blower Scroll (10.5 Blower) 1
- 25 7542-3 Faceplate (10.5 Blower) 1
- 26 7526 Intake Tube (10.5 Blower) **
- 27 5595-2 Intake Cover/GHS 1
- 28 7833 Cable Clamp (7/8 x 1/4) 1
- 29 7528-2 Skid Bar (10.5" Blower) 1
- GHS GROUP
- GHS POWERFIL® ASSEMBLY
- 1 5557 Motor Mount, Powerfil® 1
- 2 5551-3 Bearing Cap, Powerfil® 1
- 3 5551-1 Pivot Bearing (#S3PP) 2
- 4 5552 Ball Joint (1/4-28) 2
- 5 5518-2 Pivot, Delivery Spout 1
- 6 5517-2 Pivot Mount 1
- 7 5558-1 Powerfil® Push Rod 1
- 8 5553-3 Bushing, Powerfil® Actuator 4
- 9 5558-2 Powerfil® Actuator Rod 1
- 10 5553-1 Compression Spring (1/2 x 2) 2
- 11 5554 Actuator Arm 1
- 12 5519-3 Motor Mount Nut (5/8-24) *
- 13 5519-2 Motor Mount Washer *
- 14 5519 Actuator Motor (12/24V) 1
- 15 5977 Grommet (1/2 x 7/8 x 1/16) 1
- GHS POWERFIL® ASSEMBLY
- GHS 7.0 BUSHEL CATCHER & EXHAUST DEFLECTOR ASSEMBLIES
- 1 7509-3 Channel Bottom 2
- 2 7505 Mustache Spring 2
- 3 7507 Screen Seal (27-1/2) 1
- 4 7856-1 Edge Molding (26") 1
- 5 7509-2 Channel Top 2
- 6 7512-2 Removable Screen (3/16 Hole) 1**
- 7 7506 Knob (10-24) Threaded Insert 2
- 8 7509-4 C-Channel 1
- 9 7504-3 Hinge (27") 1
- 10 7504-1 Exhaust Deflector (Two Piece Set) 1
- 11 7504-8 Deflector Mount Doubler 2
- 12 5583 Handle 1
- 13 5588 Rubber Bumper (.75 x .50) 2
- 14 7522 Side Strap, Door (7.0) 2
- 15 7610 Catcher Dump Plate 1
- 16 7610-1 Dump Plate Slide 2
- 17 7513-2 7.0 Mounting Frame Doubler 1
- 18 5281-5 Clevis Pin (1/4 x 0.80) 2
- 19 7503 7.0 Mounting Frame 1
- 20 5522-1 Hinge Backup Plate, LH 1
- 21 7503-9 Pivot Bushing (5/16 x 5/8) 2
- 22 7510-1 7.0 Bushel Catcher, Including Door 1
- 23 7514-10 7.0 Door Frame 1
- 24 5155-12 5/16 Ball Stud 2
- 25 5147 Spring Clip 4
- 26 5155-2 Gas Spring Cover 2
- 27 5155 Gas Spring Assembly / Catcher Door 2
- 28 5524-1 Flanged Hinge Bearing 2
- 29 5155-13 3/4 Ball Stud 2
- 30 5523-6 Gas Spring Plate 2
- 31 7532 Handle, Catcher Lift 2
- 32 7533 Backing Plate, Handle 2
- 33 5155-15 Box Support, Gas Spring 2
- 34 7557-10 7.0 Wire Harness Channel 1
- 35 5976 Grommet (3/8 x 11/16) 1
- 36 5976-2 Grommet (3/16 x 3/4) 1
- 37 5522-2 Hinge Backup Plate, RH 1
- 38 7508 Safety Latch 1
- 39 7584 Reinforcing Strap 2
- 40 7514-1 Backup Plate, Catcher Door 1
- GHS 7.0 BUSHEL CATCHER & EXHAUST DEFLECTOR ASSEMBLIES
- GHS 9.5 BUSHEL CATCHER ASSEMBLY
- 1 8514-11 9.5 Door Frame 1
- 2 8510-1 9.5 Bushel Catcher, Including Door 1
- 3 7514-1 Backup Plate, Catcher Door 1
- 4 5588 Rubber Bumper (.75 x .50) 2
- 5 8516 Side Strap, Door / 9.5 2
- 6 5583 Handle 1
- 7 5522-1 Hinge Backup Plate, LH 1
- 8 7503-9 Pivot Bushing (5/16 x 5/8) 2
- 9 8503-2 Mounting Frame 1
- 10 5155-12 5/16 Ball Stud 2
- 11 5147 Spring Clip 4
- 12 5155 Gas Spring Assembly / Catcher Door 2
- 13 5155-2 Gas Spring Cover 2
- 14 5524-1 Flanged Hinge Bearing 2
- 15 5155-13 3/4 Ball Stud 2
- 16 5523-6 Gas Spring Plate 2
- 17 7533 Backing Plate, Handle 2
- 18 7532 Handle, Catcher Lift 2
- 19 5155-15 Box Support, Gas Spring 2
- 20 8117 9.5 Wire Harness Channel 1
- 21 5976 Grommet (3/8 x 11/16) 2
- 22 5522-2 Hinge Backup Plate, RH 1
- 23 7508 Safety Latch 1
- 24 7584 Reinforcing Strap 2
- 25 5281-5 Clevis Pin (1/4 x .080) 2
- 26 8513-3 9.5 Mounting Frame Doubler 1
- GHS 9.5 BUSHEL CATCHER ASSEMBLY
- INSTRUMENT PANEL ASSEMBLY
- 1 7307-2 Instrument Panel Cover (Optional) **
- 2 7307 Panel Frame 1
- 3 7823-4 Decal, Instrument Panel 1
- 4 7307-6 Panel Faceplate 1
- 5 7386 Panel Gasket 1
- 6 7960-6 Ignition Key (1 Set) *
- 7 7960-5 Ignition Switch (with Keys) 1
- 8 8996-2 Red Indicator Light Assembly 2
- 9 7941-3 Boot, Circuit Breaker 2
- 10 7941-5 Circuit Breaker (7 Amp) 1
- 11 7941-2 Circuit Breaker (10 Amp) 1
- 12 8990-1 Hourmeter (SenDec) 1
- 13 5995 Toggle Switch (Off-On) 1
- 14 5995-2 Switch Boot 1
- 15 7306-14 Water Temperature Gauge 1
- 16 8997 Voltmeter Gauge 1
- 17 7947-3 Wire Harness, Instrument Panel 1
- 18 5975-1 Cable Tie (18# x 3-3/4") 2
- 19 8996-4 Red Indicator Lens 2
- 20 8996-3 Indicator Bulb *
- 21 7307-1 Shock Mount (1.0 x .25) 3
- 22 7391 Panel Box Mount Plate 2
- 23 7385-1 Panel Box W/Graphic 1
- 24 7977-1 Grommet (1/8 x 1-1/16) 1
- 25 7307-16 Lining, Panel Box (1/8) 1
- 26 8536 Warning Horn 1
- 27 6941 Relay Switch (30/40 Amp) 3
- 28 7947-8 Jumper Wire 1
- INSTRUMENT PANEL ASSEMBLY
- ELECTRICAL ASSEMBLY
- 1 5975-1 Cable Tie (18# x 3-3/4") 5
- 2 5933 Battery Terminal Insul., Red (+) 1
- 3 5844 Battery Hold-Down Bar 1
- 4 5839 Hook Bolt 2
- 5 6392 Battery Protector Plate 1
- 6 7390-1 Battery Pan 1
- 7 7910 Battery (12V/340CCA/Dry) 1
- 8 5932 Battery Terminal Insul., Black (-) 1
- 9 6923 Battery Cable (-) 1
- 10 5975-3 Cable Tie (50# x 7") 4
- 11 5833 Cable Clamp (1/4) 1
- 12 5942-4 PTO Safety Switch (NO) 1
- 13 7940-9 Wire Harness 1
- 14 5832 Cable Clamp (1/2) 5
- 15 7944 7.0 Wire Harness 1*
- 16 7938 Lead Wire (Battery Charge) 1
- 17 7306-10 Switch (235 Deg., 1/4-18 NPT) 1
- 18 7306-11 Switch (205 Deg., 3/8-18 NPT) 1
- 19 6941 Relay Switch 30/40 Amp (NC) 2
- 20 7433 Resistor, Ceramic / .4 OHM 1
- 21 7833 Cable Clamp (7/8 x 1/4) 2
- 22 7948-2 Time Delay Harness 1
- 23 7948-1 Time Delay Module 1
- 24 7428-1 Fan Control Module W/P Plug 1
- 25 5942-5 Safety Switch (NO) 1
- 26 5941-5 Safety Switch (NO) 1
- 27 7203-6 Riser Plate, Seat Switch 1
- 28 5977-6 Grommet (1 x 1-1/4) 1
- 29 5975-5 Wire Clip, Self-Mount 3
- 30 7943 Battery Cable (+) 1
- 31 8941 Circuit Breaker (30 Amp) 1 (Auto Reset/Sealed)
- 32 7857-10 Breaker, Mount Bracket 1
- 33 7941 Circuit Breaker (40 Amp) 1 (Auto Reset/Sealed)
- 34 7940-5 Circuit Breaker Jumper 1
- ELECTRICAL ASSEMBLY
- ELECTRICAL ASSEMBLIES (GHS 7.0 / 9.5 BUSHEL COMPONENTS)
- 1 5975-3 Cable Tie (50# x 7") 2
- 2 5536-2 Horn, Full Signal *
- 3 7835 Frame Clip (3/16) 6
- 4 8950 9.5 Wire Harness 1 7944 7.0 Wire Harness *
- 5 5833 Cable Clamp (1/4) 2
- 6 5980-3 Wire, Grass-Pak® Switch 1
- 7 5592-11 Liquid Tight Plug 1
- 8 5592-10 Grass-Pak® Switch Module 1
- 9 5594-5 Vane Assembly, Grass-Pak® Switch 1
- 10 5977-2 Grommet, Cut (1/8 x 3/8) 1
- ELECTRICAL ASSEMBLIES (GHS 7.0 / 9.5 BUSHEL COMPONENTS)
- ELECTRICAL CONNECTORS
- 1 5996-1 16-14 GA Butt Connector *
- 2 5996-11 12-10 GA Butt Connector *
- 3 7942-14 14-16 GA Shrink Connector *
- 4 7942-13 10-12 GA Shrink Connector *
- 5 5995-1 Wire Terminal Adapter *
- 6 5996-4 16-14 GA Bullet Conn., Male *
- 7 5996-5 16-14 GA Bullet Conn., Female *
- 8 5940-4 16-14 GA Spg. Loaded Term., Female *
- 9 5940-7 Wire Clip, Female *
- 10 5996 1/4 x 16-14 GA QKS Term., Female *
- 11 5996-2 3/16 x 22-18 GA QKS Term., Female *
- 12 7996 16-14 GA QKS Term., Female *
- 13 5940-5 16-14 GA Spg. Loaded Term., Male *
- 14 5996-0 1/4 x 22-18 GA QKS Term., Male *
- 15 5996-18 16-14 GA Ring Term. (#8) Nylon Insulated *
- 16 7996-1 1/4 x 16-14 GA QKS Term., Male *
- 17 5996-8 6 GA Ring Lug (5/16) *
- 18 5996-9 22-18 GA Ring Term., #10 *
- 19 5996-10 16-14 GA Ring Term. (5/16) *
- 20 5996-12 12-10 GA Ring Term. (5/16) *
- 21 5996-13 16-14 GA Ring Term., # 10 *
- 22 5996-15 12-10 GA Ring Term. (1/2) *
- 23 5996-16 6 GA Ring Terminal (1/4) *
- 24 5996-17 16-14 GA Ring Term. (1/4) *
- 25 5996-20 12-10 GA Ring Term. (1/4) *
- 26 5996-21 12-10 GA Ring Term., #10 *
- 27 7942-4 Single Connector, Male *
- 28 8942 2-Way Connector, Male *
- 29 7942-1 2-Way Locking Connector, Female *
- 30 7942-2 2-Way Connector, Male *
- 31 7942-3 2-Way Connector, Female *
- 32 7942-10 2-Way Locking Connector, Male *
- 33 5940-8 3-Way Connector, Male *
- 34 7942-9 3-Way Connector, Male *
- 35 8944 3-Way Locking Connector, Male *
- 36 8944-1 3-Way Locking Connector, Female *
- 37 7942-11 4-Way Connector, Male *
- 38 7942-12 4-Way Connector, Female *
- 39 7942-5 5-Way Connector, Male *
- 40 5940-2 5-Way Connector, Male *
- 41 8942-1 5-Way Connector, Female *
- 42 7942-6 6-Way Connector, Male *
- 43 7942-7 6-Way Connector, Male *
- 44 7942-8 8-Way Connector, Male *
- 45 8942-2 8-Way Connector, Female *
- 46 8942-3 5-Way Connector, Male *
- 47 5940-9 3-Way Connector (M) *
- 48 7942-15 6-Way Connector (Female) *
- 49 7940-3 Packard Plug (Male) *
- 50 7940-4 Packard Plug (Female) *
- ELECTRICAL CONNECTORS
- POWER DECK LIFT KIT
- 1 8628 Linear Actuator (10" OAL) 1
- 2 8655-8 Clamp Bar 1
- 3 7503-10 Actuator Drive Bushing 1
- 4 8655-11 Bushing (5/8 x 5/16 x 1-1/16) 1
- 5 8655-10 Bushing (5/8 x 5/16 x 1-1/16) 1
- 6 8655-7 Arm, Deck Lift 1
- 7 8655-9 Cable Pull 1
- 8 8655-12 Bushing (3/4 x 1/4 x 3/4) 1
- 9 5977-1 Grommet (1/8 x 3/8) 1
- 10 8649 Wire Harness 1
- 11 5975-5 Wire Clip, Self Mount 1
- 12 6623 Toggle Switch 1
- 13 5996-21 12-10 GA Ring Terminal (# 10) *
- 14 8655-1 Hitch Pin/Cotterless (5/8) 2
- 15 8655-6 Lift Chain 2
- 16 8655-5 Cable Mount 2
- 17 5996-20 12-10 GA Ring Terminal (1/4) *
- 18 8942-3 5-Way Connector (M) *
- 19 5940-4 16-14 GA Spring-Loaded Terminal (F) *
- 20 8655-3 Cable, LH (48") 1
- 21 8655-2 Cable, RH (38.5") 1
- 22 8654 Decal, Deck Lift 1
- 23 6623-1 Switch Boot 1
- 24 6832 Cable Clamp (9/16 x 1/4) 1
- 25 5832 Cable Clamp (1/2) 1
- 26 8655-22 Base, Deck Lift 1
- 27 8655-4 Clevis Pin (5/16 x 3/4) 2
- 28 5975-3 Cable Tie (#50 x 7") 3
- 29 7942-1 2-Way Locking Connector (F) *
- 30 5940-5 16-14 GA Spring-Loaded Terminal (M) *
- POWER DECK LIFT KIT
- ARMREST KIT / TOUCH-UP PAINT / COMFORT SEAT KIT
- 1 5886-1 Armrest, RH 1
- 2 5886-6 Cover Plate, RH 1
- 3 5887 Mounting Bracket 1
- 4 5886-5 Cover Plate, LH 1
- 5 5886-2 Armrest, LH 1
- 6 5867 Touch-Up Paint, Grey (12 oz. Aerosol)
- 7 5866 Touch-Up Paint, Yellow (12 oz. Aerosol)
- 8 6103-5 Comfort Seat 1
- 9 7203 Seat Spring Plate **
- 10 7223 Compression Spring (1/2 x 1) **
- 11 7846 Washer (3/8 x 1-1/4 x 1/8) **
- 12 7204 Shoulder Bolt, Seat Mount **
- 13 7203-6 Riser Plate, Seat Switch ***
- 14 7845 Rubber Bumper (1.375 x .63) **
- 15 7440-5 Shock Mount (1-1/4 x 3/4) **
- 16 6103-42 Armrest, RH/Cordura 1
- 17 6103-41 Armrest, LH/Cordura 1
- ARMREST KIT / TOUCH-UP PAINT / COMFORT SEAT KIT
- SUSPENSION SEAT KIT / LIGHT KIT
- 1 6103-92 Armrest, RH/SS 1
- 2 NS 5/8 Nut Cover 4
- 3 NS 7/16-20 x 13/4 HHCS 4
- 4 NS 3/8 SAE Washer 4
- 5 NS Bushing, 3/4 x 3/4 4
- 6 6103-91 Armrest, LH/SS 1
- 7 6103-11 Suspension Seat 1
- 8 5941-5 Safety Switch (Normal Open) *
- 9 6103-33 Seat Mount Plate, LH 1
- 10 7223 Compression Spring (1/2 x 1) 2
- 11 5975-3 Cable Tie (50# x 7") 2
- 12 5975-1 Cable Tie (18# x 3-3/4") 1
- 13 6103-23 Wire Harness, Suspension Seat 1
- 14 7846 Washer (3/8 x 1-1/4 x 1/8) 2
- 15 7204 Shoulder Bolt, Seat Mount 2
- 16 5453-20 Steering Lever Handle (+1"), Adj. 2
- 17 5977-5 Grommet (5/8) 2
- 18 5841 Retainer Washer (3/8 x 1-1/4) 2
- 19 7845 Rubber Bumper (1.375 x 0.63) 2
- 20 7440-5 Shock Mount (1-1/4 x 3/4) 2
- 21 6103-34 Seat Mount Plate, RH 1
- 22 7989-2 Light Assembly (Halogen) 2
- 23 7989-3 Wire Harness Extension 2
- 24 7834-1 Half U-Wire Clip 4
- 25 5996-4 16-14 GA Bullet Cntr. (M) 3
- 26 5996-5 16-14 GA Bullet Cntr. (F) 2
- 27 7993 Mount Bracket, Lights 1
- 28 7995-3 Power Lead Wire Assembly 1
- 29 5977-1 Grommet (1/8 x 3/8) 2
- 30 5975-5 Wire Clip, Self-Mount 3
- 31 5975-1 Cable Tie (18# x 3-3/4") 1
- 32 5996 1/4 x 16-14 GA QDF Terminal 1
- SUSPENSION SEAT KIT / LIGHT KIT
- POWER DUMP KIT (7.0 BUSHEL GHS MODELS ONLY)
- 1 5522-20 Hinge Backup Plate/RH/PD 1
- 2 7620-3 Pivot Bushing (1/2 x 9/16) 2
- 3 7612-4 Door Actuator Arm, RH 1
- 4 7612-3 Door Actuator Arm, LH 1
- 5 5522-10 Hinge Backup Plate/LH/PD 1
- 6 7610-5 Extension Spring (1/4 x 2-7/8) 1
- 7 7523-2 Clevis Pin (1/4 x 5/8) 2
- 8 7623 Power Dump Cable 2
- 9 5975-7 Cable Tie (50# x 11") 1
- 10 7621 Linear Actuator/7.0 1
- 11 5552 Ball Joint (1/4-28) 2
- 12 7628-1 Channel Angle, RH 1
- 13 7620-9 Roller Wheel 2
- 14 7629 Channel Angle, LH 1
- 15 5830 Grease Fitting 3
- 16 7626-0 Actuator Mount 1
- 17 7624-1 Roller Bearing Bolt 1
- 18 5842-1 Washer, Axle Spacer 1
- 19 7627 Front Actuator Mount 1
- 20 7624 Sealed Needle Bearing 1
- 21 7630-3 Ram Pivot and Spacer 1
- 22 7625 Fork 1
- 23 5975-1 Cable Tie (18# x 3-3/4") 1
- 24 5975-3 Cable Tie (50# x 7") 5
- 25 7622 Wire Harness 1
- 26 6623 Toggle Switch 1
- 27 6623-1 Switch Boot 1
- 28 7633 Decal, Power Dump 1
- 29 7104-5 Rear Body Panel, LH 1
- 30 8105-4 Rear Body Panel, RH 1
- 31 7620-12 Cable Rod Guide (7.0) 2
- 32 7620-6 Cable Guide 2
- 33 7613-1 Door Actuator, 7.0/9.5 2
- POWER DUMP KIT (7.0 BUSHEL GHS MODELS ONLY)
- POWER DUMP KIT (9.5 BUSHEL GHS MODELS ONLY)
- 1 5522-20 Hinge Backup Plate/RH/PD 1
- 2 7620-3 Pivot Bushing (1/2 x 9/16) 2
- 3 7612-4 Door Actuator Arm, RH 1
- 4 7612-3 Door Actuator Arm, LH 1
- 5 5522-10 Hinge Backup Plate/LH/PD 1
- 6 7610-5 Extension Spring (1/4 x 2-7/8) 1
- 7 7523-2 Clevis Pin (1/4 x 5/8) 2
- 8 7623-2 Power Dump Cable 2
- 9 5975-7 Cable Tie (50# x 11") 1
- 10 7721 Linear Actuator/9.5 1
- 11 5552 Ball Joint (1/4-28) 2
- 12 8620-5 Guard, Power Dump Motor/9.5 1
- 13 7628-1 Channel Angle, RH 1
- 14 7620-9 Roller Wheel 2
- 15 7629 Channel Angle, LH 1
- 16 5830 Grease Fitting 3
- 17 7636-1 Actuator Mount, 9.5 1
- 18 7624-1 Roller Bearing Bolt 1
- 19 5842-1 Washer, Axle Spacer 1
- 20 7627 Front Actuator Mount 1
- 21 7624 Sealed Needle Bearing 1
- 22 7630-3 Ram Pivot and Spacer 1
- 23 7625 Fork 1
- 24 5975-1 Cable Tie (18# x 3-3/4") 1
- 25 5975-3 Cable Tie (50# x 7") 5
- 26 7622 Wire Harness 1
- 27 6623 Toggle Switch 1
- 28 6623-1 Switch Boot 1
- 29 7633 Decal, Power Dump 1
- 30 7104-5 Rear Body Panel, LH 1
- 31 8105-4 Rear Body Panel, RH 1
- 32 7620-6 Cable Guide 2
- 33 7613-1 Door Actuator, 7.0/9.5 2
- POWER DUMP KIT (9.5 BUSHEL GHS MODELS ONLY)
- HI-DUMP KIT
- 1 7613-1 Door Actuator, 7.0/9.5 2
- 2 7612-4 Door Actuator Arm/RH 1
- 3 7612-3 Door Actuator Arm/LH 1
- 4 7620-6 Cable Guide 2
- 5 7523-2 Clevis Pin W/Hole (1/4 x 5/8) 2
- 6 7623-2 Power Dump Cable/9.5 2
- 7 5552 Ball Joint (1/4-28) 2
- 8 8402-3 Backup Plate 1
- 9 7628-1 Channel Angle/RH 1
- 10 8404-4 Channel Angle/LH 1
- 11 7146 13mm Ball Stud 2
- 12 7145 Gas Spring Assembly 1
- 13 7147 Spring Clip 2
- 14 5841 Retainer Washer (3/8 x 1-1/4) 4
- 15 8845 Rubber Bumper (30mm OD x 40mm) 3 5/16-18 Female
- 16 8404-6 Clevis Pin (1/2 x 1-1/2) 1
- 17 8402-6 Catcher Pivot Plate 2
- 18 7620-9 Roller Wheel 2
- 19 8402-2 Catcher Pivot Arm (Includes Item # 20) 1
- 20 5830 Grease Fitting 5
- 21 8404-5 Clevis Pin (1/2 x 1-1/4) 1
- 22 8402-4 Upper Cylinder Mount Arm 1
- 23 8402-1 Catcher Frame 1
- 24 7845 Rubber Bumper (1.375 x .63) 2
- 25 8401-4 Upper Pivot Shaft 1
- 26 8401-5 Pivot Arm (Includes Item # 27) 1
- 27 8401-9 Decal, Safety Lockout Arm 1
- 28 5683 Pivot Bearing 2
- 29 8401-1 Torsion Spring (1-1/2) 1
- 30 8401-6 Spring Bushing 1
- 31 8401-3 Safety Lockout Arm 1
- 32 8401-2 Safety Lockout Spring 1
- 33 8400-3 Rear Pivot/LH (Includes Items # 20 & 28) 1
- 34 5214-8 Ball Joint (7/16-20) Hi Strength 2
- 35 8400-8 Decal, Hi-Dump 1
- 36 7047-5 Mount Plate 1
- 37 8430 Body Chute, Hi-Dump (10") 1
- 38 8400-10 Auxiliary Power Terminal Plate 1
- 39 8400-7 Decal, Electrical Jumper Warning 1
- 40 8400-5 Switch Mount 1
- 41 8400-9 Decal, Hi-Dump Operation 1
- 42 8400-4 Switch Cover (Includes Item # 41) 1
- 43 8400-1 Bumper/Hi-Dump Mount 1
- 44 7854 Plastic Tip/Red 1
- 45 7383-2 Body Latch Hook 1
- 46 8400-2 Rear Pivot/RH 1
- 47 8402-7 Control Lift Rod 2
- 48 5214-9 Ball Joint (7/16-20LH) Hi Strength 4
- 49 8403-13 Pump Guard 1
- 50 7847 Rubber Bumper (1.5 OD x 1.0) 1
- HI-DUMP KIT
- HI-DUMP KIT - HYDRAULIC
- 1 5833 Cable Clamp (1/4) 3
- 2 8440-1 Catcher Adapter Harness 1
- 3 8404 Dump Cylinder 1
- 4 8403-7 90˚ Fitting 12
- 5 5975-3 Cable Tie (50# x 7") 5
- 6 8403-6 Hydraulic Hose, Catcher Box Dump (73.5) 1
- 7 8403-5 Hydraulic Hose, Catcher Box Dump (67.5) 1
- 8 5835 Cable Clamp (3/4) 6
- 9 8403-3 Hydraulic Hose, Lift/Rear (11.5) 1
- 10 8404-1 Lift Cylinder 1
- 11 8403-2 Hydraulic Hose, Lift/Front (16) 2
- 12 5975-7 Cable Tie (50# x 11") 2
- 13 8404-2 Hydraulic Valve Box 1
- 14 8403-4 Hydraulic Hose, Valve to Pump (17-1/2) 2
- 15 5975-1 Cable Tie (18# x 3-3/4") 9
- 16 8403 Hydraulic Power Unit 1
- 17 8440-2 Switch Harness 1
- 18 5832 Cable Clamp (1/2) 1
- 19 8401-7 Junction Block 10-32 2
- 20 7941 Circuit Breaker 40 Amp 1
- 21 8404-9 Plastic Cover/Black 1
- 22 8404-8 Plastic Cover/Red 1
- 23 6623-1 Switch Boot 2
- 24 6623 Toggle Switch 2
- 25 8440-3 Jumper Wire 1
- 26 8440 Wire Harness/Hi-Dump 1
- 27 6941-5 Relay Switch 60 Amp (NC) 2
- 28 7833 Cable Clamp (7/8 x 1/4) 1
- 29 8403-11 Counterbalance Valve 1
- 30 8403-8 Directional Valve 2
- 31 8403-9 Coil W/Connectors 2
- 32 8403-10 Breather W/Riser 1
- 33 8403-1 Reservoir/Power Unit 1
- HI-DUMP KIT - HYDRAULIC
- NO CATCH DEFLECTOR KIT / TAIL WEIGHT KIT
- NO CATCH DEFLECTOR KIT / TAIL WEIGHT KIT
- SPREAD TAIL WHEEL AXLE KIT / SPEED UP KIT
- 1 7427-33 Recovery Tank Keeper 1
- 2 5975-3 Cable Tie (50# x 7") 1
- 3 7427-8 Overflow Hose, 36" 1
- 4 7427-3 Coolant Recovery Tank 1
- 5 7427-32 Recovery Tank Mount 1
- 6 7420-24 Heat Shield 1
- 7 7420-27 Mount Bracket 1
- 8 7420-6 Washer (2-1/2) 1
- 9 7420-5 Mount, Spread Axle 1
- 10 8769-8 Dust Cap, Deck Caster 2
- 11 8769-6 Bearing Cone (1" ID) 4
- 12 8769-5 Bearing Cup 4
- 13 7420-4 Fork Mount Tube 1
- 14 8769-7 Seal 2
- 15 7420-2 Tail Fork, Spread Axle 2
- 16 8039 Nut, Tail Wheel Axle 2
- 17 8038-1 Spacer, Tail Wheel Axle 2
- 18 7038 Tail Wheel Axle (3/4 x 5-9/16) 2
- 19 5683 Pivot Bearing 2
- 20 5830 Grease Fitting 3
- 21 7420-7 Pivot Shaft (1 x 5-1/4) 1
- 22 6238 Drive Belt (3VX345) 1
- 23 7240-1 Jackshaft Drive Pulley (3-1/2/3V) 1
- SPREAD TAIL WHEEL AXLE KIT / SPEED UP KIT
- TAIL WHEEL LOCK KIT
- 1 5995-2 Switch Boot 1
- 2 8547 Switch Mount 1
- 3 8555 Decal, Tail Lock Switch 1
- 4 5995 Toggle Switch (Off-On) 1
- 5 7942-4 Single Connector, Male 2*
- 6 5940-4 16-14 GA Spg. Loaded Term., Female 5*
- 7 5977-1 Grommet (1/8 x 3/8) 1
- 8 5975-3 Cable Tie (50# x 7") 4
- 9 8550 Wire Harness 1
- 10 5975-1 Cable Tie (18# x 3-3/4") 3
- 11 8553 Splice Tap (18-14 GA) 1
- 12 8543 Solenoid Mount 1
- 13 5830-3 Grease Fitting (45 Degree) 1
- 14 8551 Ground Wire 1
- 15 8546 Solenoid, Control Module 1
- 16 5996 1/4 x 16-14 GA QDF Terminal 5*
- 17 8552 Connector Plug & Wire Assy 1
- 18 8544 Clevis (9/16) 1
- 19 5551-1 Pivot Bearing 2*
- 20 8544-1 Bearing Spacer (1/4 ID x 9/16) 1*
- 21 8542 Tail Wheel Fork, Locking 1
- 22 8944 3-Way Locking Connector, Male 1*
- 23 8944-1 3-Way Locking Connector, Female 1*
- 24 5940-5 16-14 GA Spg. Loaded Term., Male 1*
- 25 5996-13 16-14 GA Ring Term., #10 1*
- 26 7929 Actuating Solenoid 1
- 27 8549 Sleeve, Delrin 1
- 28 8541 Plunger Rod 1
- 29 7941-4 Circuit Breaker (25 Amp) **
- TAIL WHEEL LOCK KIT
- WIDE TAIL WHEEL / ALL-TERRAIN TIRE KIT & TIRE CHAIN SET
- WIDE TAIL WHEEL / ALL-TERRAIN TIRE KIT & TIRE CHAIN SET
- LUBRICATION POINTS
- 1 Deck Caster Wheel Fork Pivot Grease 2
- 2 Blade Drive Gearbox Oil* 2
- 3 Tee Gearbox, Deck Oil* 1
- 4 Deck Caster Wheel Bearing Grease 2
- 5 Universal Joint Shaft Assembly Grease** 1
- 6 Pivot Assembly, Tilt-Up Deck Grease 4
- 7 Deck Support Arm Socket Grease 2
- 8 Body Hinge Point Oil 2
- 9 FSC Actuator Rod Pivot Pins Oil 2
- 10 FSC Lever Pivot Grease 1
- 11 FSC Lever Fork Grease 1 (Grease Slide Area)
- 12 Steering Lever Pivot Grease 4
- 13 Deck Support Arm Pivot Grease 2
- 14 Deck-to- PTO Coupling Grease 1 (Grease Slide Area)
- 15 Universal Joint Tube Assembly Grease** 1
- 16 Universal Joint Quick Connect Grease 1
- 17 Parking Brake Lever Grease 1
- 18 Gear Axle Oil*** 2
- 19 Belt Tightener Pivot, Grease 1
- 20 PTO Clutch Lever Pivot Grease 1
- 21 Clutch Actuator Push Rod Grease 2
- 22 Brake Actuator Rod and Brake Oil 3
- 23 Throttle Control Cable Ends Oil 2
- 24 Cold Start Lever Grease 1
- 25 Catcher Hinge Point Oil 2
- 26 Rear Wheel Bearings Grease 2
- 27 Engine Dipstick / Oil Filler Oil*** 1
- 28 Belt Tightener Pivot, Grease 1 Blower Drive (GHS Model Only)
- 29 PTO Gearbox Dipstick Oil*** 1
- 30 Hydrostatic Drive Oil*** 2
- 31 (FSC) Friction Body Pivot Grease 1
- 32 Throttle Control Pivot Oil 1
- LUBRICATION POINTS
- WIRING SCHEMATIC
- WARRANTY
