CONTROLS
CUTTER 24V 86039070 04/10/07
3-6
1. Key Switch
2. Emergency Shut Off Switch (Optional)
3. Speed Control Knob
4. Propel Control Lever
5. Reverse Button
6. Brush Switch
7. Brush Lift Lever
8. Solution Control Knob
9. Vacuum Switch
10. Squeegee Lift Lever
11. Squeegee Pitch Adjustment Knob
12. Squeegee Deflection Adjustment Knobs
13. Battery Charge Level Indicator
14. Parking Brake (Optional)
15. Hour Meter (Optional)
1. KEY SWITCH
Controls the power for machine functions.
To turn machine on, rotate key clockwise.
To turn machine off, rotate key
counterclockwise.
FOR SAFETY: Always remove the key
when machine is unattended or during
service to prevent unauthorized
movement.
2. EMERGENCY SHUT-OFF SWITCH
(OPTIONAL)
Shuts off machine.
To shut off machine, push the switch.
To restart machine, rotate the switch
clockwise.
3. SPEED CONTROL KNOB
Controls the speed of the machine.
To increase speed, rotate knob clockwise.
To decrease speed, rotate knob
counterclockwise.
4. PROPEL CONTROL LEVERS
Controls the machine direction, and scrub
brushes and solution flow.
To propel machine forward, squeeze either
propel lever.
The scrub brushes will not rotate and the
solution will not flow to scrub deck with the
propel levers in neutral.
5. REVERSE BUTTON
Controls the reverse function.
To propel machine backward, push the
reverse button while squeezing either propel
lever.
6. BRUSH
SWITCH
Controls the scrub brush motors.
To turn scrub brushes on, press the bottom of
the switch. The brushes will not rotate with the
propel control levers in neutral.
To turn scrub brushes off, press the top of the
switch.
