COMPONENT ACCESS
COMPONENT LOCATION
WASHER TOP
WASHER BACK
WASHER FRONT
DETERGENT DISPENSER
CENTRAL CONTROL
UNIT
FLOWMETER
PRESSURE SWITCH
VENT HOSE
TUB
ASSEMBLY
CONSOLE
FILL
VALVES
WEIGHT
SHOCK
ABSORBER
WEIGHT
PULLEY
PRESSURE
TUBE
CONNECTOR
SHOCK
ABSORBER
SHOCK
ABSORBER
DRIVE
MOTOR
BASKET
WATER
INLET
MOTOR
CONTROL UNIT
HEATING
ELEMENT
RELAY
DRAIN PUMP
ASSEMBLY
SHOCK
ABSORBER
BOOT
WEIGHT
VENT
