18
ATTACHING THE LEG LEVER TO THE LOW
PULLEY STATION
To use the Leg Lever (16), the seat must be attached
to the front upright (see ATTACHING AND REMOV-
ING THE SEAT, on page 17).
Attach the Short Cable (42) to the 3/8” x 2” Eyebolt
(64) with the Chain (37) and two Cable Clips (38).
ADJUSTING THE HEIGHT OF THE BAG ARMS
To adjust the height of the Punching Bag (30) or the
Speed Bag (31), first remove both Bags from the
weight system. Remove the two 5/16” x 5 3/4” Bolts
(90), Large Support Plates (8), and 5/16” Nylon
Locknuts (83) attaching the Punching Bag Arm (6)
and the Speed Bag Arm (7) to the Rear Upright (5).
Adjust the height of the Arms and reattach them to
the Rear Upright with the Bolts, Support Plates, and
Nylon Locknuts. Reattach the Bags to the Arms.
Note: The Punching Bag should hang so that the
top is slightly higher than the user’s head.
16
42
38
37
38
64
7
6
8 83
30
90
8
5
11
31
