Wolfcraft 6155 - Manual (Page 45)

45
REPAIR PARTS
6155 Router Table
PART NO.
116 680 221
116 670 012
116 600 136
116 600 135
116 680 223
116 670 011
116 680 217
116 680 218
116 680 219
116 680 220
116 680 222
116 710 068
116 700 078
116 730 128
116 750 135
116 730 134
116 730 126
117 040 134
116 700 066
116 730 132
116 700 070
116 730 129
116 730 130
116 730 124
116 700 068
116 730 135
117 220 182
116 700 080
117 220 181
116 700 071
116 700 065
116 730 133
116 730 125
117 040 139
117 040 140
116 730 072
116 730 127
DESCRIPTION
Miter pointer
Miter guide knob
Miter guide clamp
Retainer
Rubber shoe
Jointing fence knob
Tabletop insert, small hole
Tabletop insert, medium hole
Tabletop insert, large hole
Tabletop insert, solid
Feather flap
Phillips head screw, self-tapping (M5x12)
Pan head screw (10-32x1/2)
Hex nut (10-32)
Square nut (M6)
Toothed washer (M5)
Hex nut (M5)
Clamp plate
Carriage bolt (M6x30)
Washer (M6)
Pan head screw (M5x16)
Hex nut (M8)
Washer (M8)
Wing nut (M8)
Hex head bolt (M6x30)
Cap nut (M6)
Pivot pin
Flat head countersink screw (10-32x7/8)
Starter pin
Pan head screw (M5x12)
Carriage bolt (M6x16)
Toothed washer (M6)
Pan head screw (5-40x3/4)
Spacer bar, 1/4"
Spacer bar, 3/8"
Hex nut (M6)
Hex nut (5-40)
QTY.
1
1
1
2
4
1
1
1
1
1
3
21
3
3
2
34
18
1
1
2
18
1
2
1
1
2
1
4
1
1
24
24
24
1
1
2
2
KEY
NO.
11
12
13
15
19
22
25
26
27
28
29
33
34
35
36
38
39
18
31
32
37
43
44
45
46
47
48
49
50
30
40
41
42
51
52
53
54
H
ar
dw
ar
e
B
ag
2
P
ar
t #
1
19
9
00
8
64
H
ar
dw
ar
e
B
ag
1
P
ar
t #
1
19
9
00
8
79
H
ar
dw
ar
e
B
ag
3
P
ar
t #
1
19
9
00
8
65
H
ar
dw
ar
e
B
ag
4
P
ar
t #
11
9
90
0
86
6
ITEM
L
M
N
Q
U
X
AA
AB
AC
AD
AE
AJ
AK
AL
AM
AP
AQ
T
AG
AH
AN
SU
AV
AW
AX
AY
AZ
BA
BB
AF
AR
AS
AT
BC
BD
BE
BF
Hardware Bags
