This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the part number of the part, from the PART LIST on page 14 of this manual.

Important:

Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in the parts
bags, check to see if it has been pre-assembled.

M10 x 81mm Bolt (35)

M10 Nylon Locknut (36)

M6 x 16mm Screw (37)

M6 Washer (40)

M4 x 16mm Screw (38)

M6 x 38mm Screw (39)

M8 Nylon Locknut (44)

M8 Washer (43)

M8 x 58mm Bolt (42)

M10 x 72mm Bolt (45)

M10 x 65mm Bolt (47)

M10 x 178mm Bolt (46)

M10 Washer (41)
