TECHNICAL SPECIFICATIONS
QTFSG/QTFSD 98349 05/15/03
3-1
ITEM DIMENSION/CAPACITY
Power Source: Gas 20hp, 2 Cylinder, Liquid-Cooled
Diesel 14hp, 2 Cylinder, Liquid-Cooled
Suspension Floating I-Beam
Maximum Speed 10k/hour
Sweep Path 1200mm
Main Broom 812mm
Main Broom Diameter 355mm
Side Broom 510mm
Hopper Capacity 180 liters
Hopper Dump 1520mm
Dust Control 54ft 2 (5m 2 ) pleated filter with exclusive
cyclonic pre-filter
Brakes Dual mechanical disc with parking brake
Steering Rear wheel, rack & pinion
Tires 405mm dia. Pneumatic
Dimensions: Height 1505mm
Weight 1060 lbs.
Length 2006mm
Coverage 12,000m 2 /hr
