BULKHEAD PARTS
6
For Models: WGD9600TW1, WGD9600TA1, WGD9600TU1, WGD9600TB1
(White) (Aspen) (Ultimate Silver) (Black/Chrome)
W10189037
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 8066208 Clip−Spring
3 3394984 Door, Lint
Screen
4 3406653 Harness, Sensor
5 3394346 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut,3/8 x 16(R.H.)
9 W10128544 Cap−Plug
10 3402841 Lens,
Drum Light
11 359625 Screw, 8−18 x 1/2
12 8572105 Clip, Exhaust
Pipe
13 8533971 Screw, 8−18 x 5/16
14 8529007 Plug,
Rear Bulkhead
15 693995 Screw, 8−18 x 3/8
16 W10001120 Nut, 3/8−16 (L.H.)
17 W10124071 Bulkhead, Rear
18
3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 8066224 Exhaust Pipe
23 3394985 Housing, Outlet
24 8573713 Thermal, Cut−Off
25 W10181467 Complete Drum
Assembly
26 W10109200 Screw, 11−16 x 3/4
27 W10166807 Seal, Drum
28 W10128629 Shield,
Blower Housing
(Includes Illus.
32. )
29 90767 Screw, 8−18 x 3/8
30 W10049370 Lint, Screen
31 W10044605 Coupling, Hose
32
3390647 Screw, 8−18 x 1/2
33 3406124 Bulb, Light
34 3387223 Electrode, Sensor
35 8578825 Bracket,
Drum Light
36 W10136369 Socket Assembly
37
697772 Wheel, Blower
38 W10044615 Clip,
Push−To−Connect
39 3394986 Spring, Lint
Screen Door
40 W10044596 Valve, Water Inlet
(Includes Illus.
29,31,52,55)
41 695240 Screw, 8−18 x 1/2
42 8577274 Thermistor
43 487909 Screw, 8−15 x 1/2
44 8544362 Housing, Blower
(Includes Illus.
49.)
45 8066168 Lint Duct Assembly
46 8573824 Funnel, Burner
47 8573028 Thermostat,
High−Limit 205 F
(96 C)
48 338906 Sensor, Radiant
49 489463 Screw, 8−18 x 5/8
50 3401710 Jumper, TCO
Hi−Limit
51 3387230 Screw, 10−16 x 1
52 W10184825 Cover, Inlet Valve
53 W10113136 Baffle, Drum
54
8519245 Bulkhead, Front
(Includes Illus.
28 & 32)
55 W10044597 Bracket, Valve
56 W10044598 Hose
(Not Servicable
Included With
Illus. 57)
57 W10179730 Nozzle & Hose
Assembly
(Includes Illus.
56,59,61,62,63)
58 8299979 Grill, Outlet
59 3391018 Tie, Cable
60 697770 Seal, Cover Plate
61 W10044579 Washer, Nozzle
62 W10044580 Nut, Brass
63 W10044629 Nozzle & Screen
Assembly
64 3392519 Thermal−Fuse
(91 C)
