EXTERNAL DEVICE CONNECTIONS
22
English
The following diagram shows the external device connections.
HDMI 1
USB
HDMI 2
SPDIF
TUNER
R
L
Y
VGA
AUDIO IN
DC IN
R
L
Antenna cable /
Cable TV line
Antenna /
Cable system
PC
AUDIO OUT
AUDIO OUT
3.5 mm
stereo mini
jack cable
RGB cable
Audio
cable
SPDIF cable
HDMI-HDMI cable
DVI-HDMI cable
DVD player
with an HDMI
terminal
AC to DC
adapter
Power
outlet
Home video
game system
Camcorder
VCR
DVD
player
Digital TV
tuner
Composite AV
cable
DVD player
with a DVI
terminal
Audio
amplifier
Audio
amplifier
