LED TV BASE
17
English
LED TV BASE
INSTALLING THE LED TV BASE
1 Open the LED TV carton box.
2 Remove the LED TV base.
3 Remove the plastic bag.
4 Remove the three top carton stabilizers from the LED TV.
5 Remove the protective plastic covering the LED TV.
6 Grasp the two sides of the LED TV and then pull it out of the carton box.
7 Remove the two bottom carton stabilizers from the LED TV.
8 Lay the LED TV on a clear, flat, and stable surface.
9 Align the base to the bottom side of the LED TV and use six M4 x 62 screws
to secure it.
10 Carefully orient the LED TV in an upright position.
CAUTION:
The LED TV unit may be too heavy for one person to lift. If this is the case,
make sure to ask for assistance in handling the LED TV to prevent
physical injury and/or damage to the unit.
TUN ER R L Y VGA AUD IO IN DC IN
R L TUN ER R L Y VGA AUD IO IN DC IN
R L
TUN ER R L Y VGA AUD IO IN DC IN
R L
TUNER R L Y VGA AUDIO IN DC IN R L
