Maintenance Instructions

LUBRICATION

34

Ident

Lubrication

No.

No.

Location

Type

Places

Ident Lubrication

No.

No.

Location Type

Places

1

Deck Caster Wheel Fork Pivot

Grease

2

2

Deck Caster Wheel Bearing

Grease

2

3

Tee Gearbox, Deck

Oil

*

1

4

Blade Drive Gearbox

Oil

*

2

5

PTO Shaft Guard Hinge

Oil

1

6

Universal Joint Shaft &

Grease

**

1

Tube Assembly

7

Pivot Assembly, Tilt-Up Deck

Grease

4

8

Deck Support Arm Socket

Grease

2

9

Universal Joint Quick Connect

Grease

1

Spline (Grease Slide Area)

10

Tilt-Up Roller Wheel

Oil

2

11

Ground Drive Belt Idler Arm

Grease

1

(not visible - access side of body)

12

Throttle/Choke Control Pivot

Oil

1

(on Control Panel) & Cable End

13

PTO Clutch Lever Pivot

Grease

3

14

Parking Brake Pivot

Oil

1

15

Engine Oil

Oil

***

1

16

Steering Control Linkage

Grease

2

17

Tail Wheel Fork Pivot &

Grease

2

Wheel Bearing (not shown)

18

Clutch Actuator Push Rod

Grease

1

19

Deck Support Pivot Arm

Grease

2

*

Gearboxes are permanently lubricated and
sealed requiring no scheduled lubrication.
Oil level should be checked only when an oil
leak is noted. Refer to Mower Deck Gear-
box Lubrication
in this section.

**

Lubricate every eight (8) hours.

***

Refer to Engine Oil in this section.

NOTE: DSD42 Deck is shown for reference. For oth-

er Deck Lubrication Points, Refer to Deck and
Carrier Frame

Illustrated Parts Manual

.
