TECHNICAL SPECIFICATIONS

CUTTER 36V (SCE) 86037030 12/05/06

3-1


ITEM DIMENSION/CAPACITY
Nominal power

2160 W

Rated Voltage

36 Volt DC

Rated Amperage

60 amps

Batteries

6 x 6 volt 250-305-335 AH @ 20 Hr rate

Scrub Brush Motors

2 x .75 hp (.56 kW)

Vacuum Motor

3 Stage .75 hp (.56 kW)

Propelling Motor

.75 hp (.56 kW)

Mass (GVW)

1265 lb (574 kg) w/335 AH batteries

Weight empty without batteries

433 lb (196 kg)

Solution Control

Gravity feed, fully variable with automatic shut-
off in neutral

Solution tank capacity

32 gal (118 L)

Recovery tank capacity

35 gal (123 L)

Scrub brush diameter 32 in. (81 cm) scrub head

16 in (41 cm)

Scrub brush pressure

Mechanical, 80 lbs floating
130 lbs restricted (356n-578n)

Scrub brush speed

200 rpm

Tires

2 x 12 in (30.5 cm) Non-Mark Foam Fill

Casters

2 x 4 in (10.2 cm) polyurethane, Non-Mark

Foundation Pressure

64 lbs/in² (441 kPa)

Maximum Speed

3.2 miles/hour (5.2 kW/hour)

Coverage with 32 in. (81 cm) scrub head

36,250 ft²/hr @ 3.0 mph with 2 in overlap *

Frame Construction

Powder coated steel

Brakes (optional)

Tire lock parking

Minimum aisle u-turn width with 32 in. (81 cm) scrub head

69 inches (175 cm)

Maximum rated climb and descent angle with empty tanks and
without optional parking brake

2%

Maximum rated climb and descent angle with full tanks and
without optional parking brake

2%


*

Cleaning rate results will vary depending on floor type, building structure, etc.
