SPARE PARTS LIST
No. CODE DESCRIPTION No. CODE DESCRIPTION
1
C8111015 • BURNER BACK COVER
2 3007077 • CRUSHABLE METAL WASHER 3/8” ID
3 3007568
•
BLEEDER
4 3007028
•
O-RING - PUMP PRESSURE REGULATOR
5 3007202 • REGULATOR SCREW
6 3007162 C7010002
•
O-RING - PUMP COVER
7 3005719
•
PUMP SCREEN
8 3006925 • VALVE STEM
9 3007203
•
PLATE - VALVE STEM RETAINER
10 3007029 • O-RING - VALVE STEM UPPER
46
11 3007156 • O-RING - VALVE STEM LOWER 47 C5320037
•
WIRING HARNESS
12 3007581
•
NOZZLE OUTLET FITTING
48 C7001330
•
BF5 SBT WELDED 4.25" COMPLETE
13
3007087 • CRUSHABLE METAL WASHER 5/8” ID
14 3006553 • COIL U-BRACKET AND RETAINER NUT
15 3002279
•
COIL
16 3007802 • PUMP
17 3000443 • PUMP DRIVE KEY
18 3005843
•
MOTOR
19 3007316
•
AIR TUBE COVER PLATE
20 3002278
•
PRIMARY CONTROL SUB BASE
21 3001157 C7001029 • PRIMARY CONTROL 530SE/C
22 3002280
•
PHOTOCELL
23 3008079 • BURNER FRONT PLATE
24 3000932
•
MOVEABLE FLANGE
25 3020248 • MOUNTING GASKET
26 3008024
•
OIL SUPPLY TUBE & ADAPTER FITTING
27 3005869 • ELECTRODE PORCELAIN
28 3007627 • PUMP-COVER OPENING-BURNER RESET
29 3007630
•
GASKET - BURNER COVER
30 3000681
•
MANUAL AIR DAMPER REGULATOR
31 3008021
•
AIR DAMPER
32 C7001337 • BF5 SBT WELDED 4.25" TUBE ONLY
33 3005844
•
CAPACITOR 12.5 µF
34 3005708 • FAN
35 3007706
•
PLUG
36 3008825 • DRIP
37
38
39 3002361 • REGULATOR ASSEMBLY
40 3008891
•
ELECTRODE ASSEMBLY
41 3006977
•
TURBULATOR DISC
42 3006966
•
ELECTRODE SUPPORT
43 3006965
•
NOZZLE ADAPTER
44 3002363 • NOZZLE OIL TUBE
45
C7001084 •
AL 1009 POST PURGE DEVICE KIT
46
C5332055 • AIR PRESSURE SWITCH
UO3 (0,6" wc)
C5332056 • AIR PRESSURE SWITCH UO4-UO5 (0,7" wc)
