Introduction
Congratulations! You have purchased one of
Winegardís latest developments in the mobile satel-
lite reception product line óthe Moviní View
TM .
This system, used with your digital satellite receiver,
will deliver the best reception possible using GPS
(Global Positioning System) and precision gyro-
scopes.
How Does Digital Satellite
TV Work?
Satellite programming originates from an ìuplinkî
facility on Earth ó the facility receives many signals
from different sources, combines the signals digitally
and transmits to the satellites. The satellites (22,300
miles above Earth) receive the uplink signal, amplify
it and then transmit it back to earth in the
Ku frequency band. This signal
is concentrated and reflected to
the LNBF* located at the ìfocal
pointî of the dish. The LNBF
amplifies and converts the signal to
the 950 to 2050 MHz range. The signal
is then passed through a coaxial cable
to the receiver where individual channel
selection and processing take place.
Introduction/How Does Digital Satellite TV Work?
PROGRAMMING UPLINK
CONTROL CENTERS
HIGH POWER KU-BAND
DOWNLINK SIGNAL
WINEGARD DIGITAL SATELLITE
SYSTEM ANTENNA
RECEIVER
UPLINK SIGNAL
TELEVISION
SET
EXPRESSVUÆ - 1-888-SKYDISH (1-888-759-3474)
Your new Winegard RV Digital Satellite System is an
easy-to-use satellite TV reception system. Because it
mounts on the top of your recreational vehicle, it
goes where you go and provides quality reception of
digital satellite signals. Check with your program
provider for exact coverage area.
* Low Noise Block Converter Feed
For Programming information call:
DISH NETWORK
TM - 1-800-333-DISH (1-800-333-
3474)
DIRECTV
Æ - 1-800-DIRECTV (1-800-347-3288)
MV-0099 features:
ï GPS technology
ï Easy ìone-buttonî operation
ï Compatible with most digital satellite receivers
ï Ability to toggle between satellites using remote
control, if subscribing to multisatellite programming
ï Winegard warranty
