Winegard HD7080P User Manual
Engineering specifications platinum series, High definition vhf/uhf antenna model hd7080p, Clearly the world's best
GAIN
CH.2
CH.4
CH.6
CH.7
CH.9
CH.11
CH.13
CH.14
CH.32
CH.50
CH.69
dB over reference
dipole
beamwidth at half
power points
front-to-back
ratio
Shpg. Weight
Carton Dimensions
9.5 lbs.
6.25"x6.25"x101"
5.1
5
2.8
7.6
9.5
9.2
11
11.7
11.4
11
10.2
75°
77°
77°
36°
42°
45°
39°
45°
46°
41°
35°
13dB
13dB
11dB
15dB
19dB
13dB
20dB
14dB
POLAR PATTERNS
Clearly the World's Best
®
engineering specifications
PLATINUM SERIES
HIGH DEFINITION
VHF/UHF
ANTENNA
Model HD7080P
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 4/02
"UPS in shield design is a registered
trademark of United Parcel Service of
America, Inc. used by permission."
Output Impedance:
Recommended Preamp:
75 ohm
AP Series
39
25
14
90"
61.7"
110"
19.3"
3/8"
Active Elements
UHF Elements
VHF Elements
Boom Length
Turning Radius
Maximum Width
Vertical Height
Element Diameter
Made in U.S.A.
greater
than
20dB
greater
than
18dB
greater
than
20dB
