Gas dryer – Whirlpool WGD9400V User Manual
Page 2
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. W10224610
11-09-08
Gas Dryer
Page 2 of 3
Side view
Closet door with vents
Closet installation - Dryer only
A*
B
C**
(460 mm)
Steam
(Electric or Gas)
Non-Steam
(Electric or Gas)
A*
1" (25 mm)
1" (25 mm)
B
32
9
/
16
" (686 mm)
31
1
/
2
" (800 mm)
C**
5" (127 mm)
5" (127 mm)
*Required spacing
**For side or bottom venting, 0" (0 mm) spacing is allowed.
Recessed or closet installation - Dryer on pedesta
A
B
C
D*
E
F**
(460 mm)
l
Steam
(Electric or Gas)
Non-Steam
(Electric or Gas)
A
1" (25 mm)
1" (25 mm)
B
27" (686 mm)
27" (686 mm)
C
1" (25 mm)
1" (25 mm)
D*
1" (25 mm)
1" (25 mm)
E
32
9
/
16
" (686 mm)
31
1
/
2
" (800 mm)
F**
5" (127 mm)
5" (127 mm)
*Required spacing
**For side or bottom venting, 0" (0 mm) spacing is allowed
NOTE:
Some models are not recommended for recessed or closet
installation.
®
RECESSED AREA AND CLOSET INSTALLATION
For closet installation, with a door, the minimum ventilation openings in the top and bottom of the door are required.
Louvered doors with equivalent air ventilation openings in the top and bottom are acceptable.
RECOMMENDED INSTALLATION SPACING FOR CABINET INSTALLATION
NOTE:
Some models are not recommended for cabinet installation.
For cabinet installation, with a door, minimum ventilation
openings in the top of the cabinet are required.
A*
B*
C*
D**
E
F*
H
I
G
Steam
(Electric or Gas)
Non-Steam
(Electric or Gas)
A*
7" (178 mm)
7" (178 mm)
B*
7" (178 mm)
7" (178 mm)
C*
9" (229 mm)
9" (229 mm)
D**
5" (127 mm)
5" (127 mm)
E
32
9
/
16
" (686 mm)
31
1
/
2
" (800 mm)
F*
1" (25 mm)
1" (25 mm)
G
1" (25 mm)
1" (25 mm)
H
27" (686 mm)
27" (686 mm)
I
1" (25 mm)
1" (25 mm)
*Required spacing
**For side or bottom venting, 0" (0 mm) spacing is allowed.
PRODUCT MODEL NUMBERS
WGD9200S
WGD9300V
WGD9400S
WGD9400V
WGD9500T
WGD9600T
