Walker PERFAERATORTM PA6685 - Manual (Page 24)

ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
Use only genuine Walker ® replacement parts. Effective Date 02-06-08
22
POWER TRANSMISSION COMPONENTS
Power Transmission Components
1 6683-2 U-Joint Shaft 1
(Includes Items # 2, F076, F149 & F318)
2 6875 Decal, PTO Alignment Arrow 1
3 6683-6 PTO Gearbox/Shear 1
4 6685 Perfaerator Chain (#50 x 88 Links) 1
5 6685-14 Gearbox Sprocket, Shear 1
6 6685-3 Idler Sprocket 1
Fasteners
F004 1/4-20 Keps Nut 1
F013 3/8-16 Whiz Locknut 5
F041 3/8-16 x 1-3/4 Hex Bolt 1
F051 3/8 SAE Washer 2
F076 3/8-16 x 5/8 SQH Set Screw 1
F123 1" External Snap Ring 1
F149 1/4 x 1/4 x 1-1/2 Key 1
F290 3/8-16 x 5 Hex Bolt 4
F318 3/8-16 x 3/4 SQH Set Screw 1
F383 1/4-20 x 2 Shear Bolt Grade 2 1
