TECHNICAL SPECIFICATIONS
86324140 AXCESS 03/25/09
3-1
VACUUM PORTION: (Carry unit)
ITEM DIMENSION/CAPACITY
Vacuum Motor
High Performance, single stage
Vacuum Motor Rated Power 1000 Watts
Vacuum Motor Maximum Power 1200 Watts
Suction 225 Mbar (2300 mm WS)
Waterlift 92 in (234 cm)
Air Flow 102 cfm (48 l/s)
Filter Bag Capacity 3.5 litres, 3 layer, enclosed, top-loading
Weight
-Axcess 12
-Axcess 15
17 lbs (7.7 kg)
17.4 lbs (7.9 kg)
Dimensions - Height 48 in (123 cm)
Housing Injection molded, high impact ABS and PP plastic
Cable 40 in (12 M) 18/3 SJT
POWER HEAD: (Detachable Head unit)
ITEM DIMENSION/CAPACITY
Brush Motor Rated Power
- 12 in (30 cm)
- 15 in (38 cm)
175 Watt
200 Watt
Working Width of Powerhead
- Axcess 12
- Axcess 15
12 in (30 cm)
15 in (38 cm)
Brush Drive
Non-slip Tooth Belt, enclosed, electronic safety clutch
and speed control.
Brush Speed 2700 rpm (5400 brush contacts per minute)
Wheels 2 in (5.2 cm) dia. rubberized
