CONTROL PANEL PARTS
6 8180206
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
8181885 Platinum
8181886 Blue
2 8181905 User Interface
3 8181860 Button, Power
4 8181861 Button, Start
5 Button Set,
Soil Level
8181863 Platinum
8181882 Blue
6 8181862 Button,
Pause/Cancel
7 Button Set,
Options
8181889 Platinum
8181892 Blue
8 Button Set,
Spin/Temperature
8181865 Platinum
8181884 Blue
9 8181868 Light, Indicator
(Status)
10 8181856 Window, Display
11 8181908 Light, Indicator
(7 Lights)
12 8181871 Light, Indicator
(3 Lights)
13 8181639 Brace, Front Top
14 8181640 Channel, Water
15 8181923 Microcomputer,
Machine Control
16 8181756 Screw
17 8181783 Harness, Wire
18 8181906 Light, Indicator
(Program)
19 8181907 Light, Indicator
(2 Lights)
20 8181855 Bezel, Knob
21 8181857 Overlay, Door
22 8181858 Medallion
23 Knob, Control
8181859 Platinum
8181881 Blue
24 8181852 Endcap, Left
25 8181853 Endcap, Right
For Models: GHW9100LW2, GHW9100LQ2
(White/Platinum) (White/Blue)
