Whirlpool GHW9100LW2 - Manual (Page 10)

TUB AND BASKET PARTS
10 8180206
Illus. Part
No. No. DESCRIPTION
1 8182132 Nut, Pulley
2 8181671 Pulley
3 8181670 Belt
4 8181745 Grid, Ventilation
5 8181744 Pipe, Ventilation
6 8181746 Clamp
7 8181743 Hose, Exhaust
8 8181912 Tub, Rear
9 8181913 Counterweight,
Rear
10 8181673 Gasket, Tub
11 8181914 Basket
12 8181669 Baffle, Tub
13 8181748 O−Ring
14 8181731 Airtrap
15 8181645 Counterweight,
Front
16 8181762 Spring,
Suspension
17 8181647 Bolt
18 8181742 Clamp
19 8181794 Hose, Tub to
Dispenser
20 8181667 Clamp
21 8181825 Tub, Front
22 8181648 Nut, Push−In
23 8181646 Shock Absorber
24 8181705 NTC
25 8181829 Seal, Rubber
Following Parts Not Illustrated
8182126 Screw, Baffle
For Models: GHW9100LW2, GHW9100LQ2
(White/Platinum) (White/Blue)
