CABINET PARTS
5
For Model: CEM2760TQ0
(White)
W10119487
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 3393008 Screw, 10−16 x 1/2
2 3353948 Bracket, Lock
3 3391846 Clip, Front
Panel (2)
4 W10045050 Screw, 10−16 x 1/2
5
3394881 Switch, Broken
Belt
6 3397659 Block, Terminal
7 8310656 Cabinet
8 3392100 Foot, Dryer
(Plastic)
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 697750 Plug, Multivent
13 3388672 Pulley Assembly
14 3391915 Screw, 10−16 x 1
15 3394331 Plate, Cover
16 3394081 Wire, Belt Switch
17 356674 Cone, Wedge
18 233520 Washer, Thurst
19 297092 Clip (2)
20 690997 Tri−Ring
21 3389247 Hinge And Pin (2)
22 63554 Rivet (2)
23 3391943 Boot, Foot
24 693152 Bumper
25 697773 Screw, 6−20 x 7/8
26 3389249 Nut, "U" (4)
27 8538264 Motor Assembly
(60 Hz.)
28 8066184 Pulley
30 3387610 Belt, Drive
31 3390902 Clip, Door
Hinge (2)
32 3387118 Bracket, Motor
33 3392186 Washer
34 279318 Terminal, Brass
& Tinned (3)
(Includes Ill. 35)
35 279393 Terminal Block
Screw Kit (For
Terminal Block)
36 3390663 Screw, 10−16 x 1/2
37 8533974 Screw, 10−32 x 5/8
39 3388674 Bracket, Idler
41 3406109 Door Switch
Assembly
42 98129 Screw,
6−20 x 1−1/16
44 3387242 Seal, Front Panel
45 342055 Screw, 8−18 x 1/2
46 3388229 Retainer
47 3392563 Door, Rear
48 694091 Screw, 8−18 x 3/8
49 3387872 Door, Front
51 3393081 Front Panel
52 696144 Strike, Door
55 693995 Screw, 8−18 x 3/8
57 3390735 Seal, Door
58 3392538 Catch, Door
Assembly
59 3398948 Wire, Jumper
60 3389522 Handle, Door
61 697215 Panel, Toe
64 8066120 Lever, Snap
Switch
65 279731 4" − 90 Elbow
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
66 279818 White
