TOP AND CONSOLE PARTS
3
For Model: CEM2760TQ0
(White)
W10119487
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8577208 Instructions.
Installation
8576821 Wiring Diagram
W10119487 Service Parts List
2 357213 Nut,Push−In
3 3361029 Bracket, Control
4 8316634 Panel, Control
5 8316516 Cap, End (R.H.)
6 3949734 Cap, End (L.H.)
7 97787 Screw, 11−16 x 3/4
8 3954665 Top
9 3347825 Plate−Mounting (2)
10 98445 Screw, 10−16 x 3/4
11 8316437 Switch, Pushbutton
12 3348109 Lens Light
(Amber)
13 351297 Plug, Harness
14 689559 Nut, Push−In
15 8533971 Screw, 8−18 x 5/16
16 303921 Screw, 8−32 x 3/8
17 8281182 Screw
8−18 x 1−1/4
18 3978608 Panel, Rear
(Upper)
19 3390647 Screw, 8−18 x 1/2
20 8316640 Light, Indicator
Assembly
21 8568314 Strap, Console
22 8576528 Harness, Main
23 717252 Receptacle
(2−Way)
24 717253 Receptacle
(2−Way)
25 8316433 Pushbutton
26 3954761 Plate,
Chute Adapter
(Includes
Illus. 51)
27 3395683 Housing,
Connector
28 357572 Clip, Ground
29 3391018 Tie, Cable
30 3936144 Connector,
3−Circuit
31 3406994 Case, Meter
32 3954807 Kit, Vertical
8−Coin
(Includes
Illus. 59−62−63
66−67−68 & 69)
33 387371 Lock, Plug
Also Available
358290 Top Lock
34 8317342 Cover,
Terminal Block
35 3349065 Screw, 5/16−24 x 1
36 3390814 Screw, 8−18 x 3/8
37 W10045440 Timer,
(Includes
4−Pin Cam)
40 Timing Cam
3387974 3−Pin (60 Min)
339855 4−Pin (45 Min)
343777 6−Pin (30 Min)
Also Available
339854 9−Pin (20 Min)
339853 12−Pin (15 Min)
41 3401682 Harness, Timer
43 3351136 Door, Service
44 3954812 Cushion, Meter
Case
45 339805 Screw,
10−32 x 3/16
46 3398893 Ground Wire
47 3394427 Clip, Harness
49 90406 Nut−Cage
51 385421 Funnel, Coin
Following Parts Supplied
On Whirlpool Coin
Equipped Models Only.
59 8316526 Security Lock/Key
and Cam Assembly
61 8318517 Bolt, Slide
Mechanism
62 8316520 Slide Mechanism
(Vertical 8−Coin)
(Dollar Vend)
Inserts
(Not Shown)
8316264 Blank
8316265 25¢
63 8316525 Money Box W/Lock
64 Key (Money Box)
(When Ordering,
Specify Vendor
and Key Number)
66 Key (Service Door)
(When Ordering,
Specify Vendor
and Key Number)
67 8316523 Extension
68 8316524 Kit, Decal
69 8316532 Installation
Instructions
Coin Kit
70 3400029 Screw, 10−32 x 3/8
Coin Mechanism Parts May be
Ordered From Whirlpool Or
The vendor(s) listed below.
ESD
270 New Jersey Dr.
Fort Washington, PA
19034
1−800−523−1510
@ info esdcoin.com
