CART
86221950 02/20/07 5-12
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86089270 78310 TUBE, CART HANDLE
2 86273740 70010 SCREW, 1/4-20 X 1.5 TAP PLTD.
3 86271380 57196 NUT, 1/2 STAR LOCK PUSH-ON
4 86005700 57104 NUT, 10-32 HEX W/ STAR WASHER
5 86259970 89507 WHEEL, 8” GREY
6 86005680 57047 NUT, 1/4-20 LOCK
7 86092130 27637 CART BASE ASM, SPOTTER
8 86006590 70088 SCREW, 10-32 X 1/2 PPHMS SS NP
9 86228340 140088 BASKET, CART
10 86232530 18010 CASTER, 2.5 DIA
11 86010630 87013 WASHER, 1/4 ID X 5/8 OD SS
- 86000030 PCT SPOTTER CART ENTIRE ASM AS KIT
