EXTRACTOR GROUP
86221950 04/27/07
5-2
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86225200 75211 1
TANK,
RECOVERY
2
86236520
34293
1 FOAM, 4.00 OD X 1.0 THICK
3
86223730
70859
2 SCREW, 8-32 X 1/2 FHMS BLK PLTD
4 86237440 35168 1
GASKET,
4.06 X 2.50 X .38
5
86223440
67511
1 RETAINER, VAC MOTOR
6
86217310
270102
1 COVER, VAC MOTOR
7A
86258440
53137
1 VAC MOTOR, 120V 2ST LNP
7B
86225500
53813
1 VAC MOTOR, 230V 2ST LNP
230V MACHINES ONLY
8
86274290
70162
6 SCR, 10-32 X 3/8 PPHMS SS
9
86225770
87494
4 WASHER, M6 X 12.5 FLAT SS
10
86237410
35160
1 GASKET, SPOTTER RECOVERY
11 86237420 35161 1 GASKET,
4.0
X 5.5” X .25 PORON
12A 86215670
140839
1 BREAKER, 8A VDE CIRCUIT
12B 86215710
141046
1 BREAKER, 5A VDE CIRCUIT
13
86010690
87068
2 WASHER, 1/8 RIVET BACKUP
14
86261160
27952
1 CAPACITOR ASM, EMI SPOTTER
230V MACHINES ONLY
15
86136540
67481
3 RIVET, M4 X 14 MM
16A 86217060
23722
1 CORD ASM, 14 X 3 25’ YLW SPOTTER
U.S. MACHINE
16B 86217040
23720
1 CORD ASM, UK SPOTTER
UK MACHINE
16C 86217070
23723
1 CORD ASM, EURO SPOTTER
EUROPE MACHINE
16D 86217080
23724
1 CORD ASM, AUST SPOTTER
AUSTRALIA MACHINE
17
86136550
67483
2 RIVET, M3 X 12 MM
18 86079650 62129 1 PLATE,
DATA
LABEL
19
86275870
70556
2 SCREW, 1/4-20 X 1.5 PHMS PLTD
20
86225760
87493
2 WASHER, M8 X 22 FLAT PLTD
21
86002010
14942
1 BOOT, 3/8 CIRCUIT BREAKER
22
86233510
27376
1 CLIP, SWITCH RETAINING
23
86225110
72194
1 SWITCH, DPST 250V 16(4) SPLASH
24 86219310 41278 1 HOUSING,
VAC
25
86237460
35173
1 GASKET, .31 x .75 x 1.98
26
86237450
35172
2 GASKET, VAC HOUSING 3/16”
27
86010640
87016
3 WASHER, #10 EXT. TOOTH LOCK
28 86218030 35354 1 GASKET,
VAC HOUSING 3/8”
29 86068560 140037 1 BRACKET,
NIPPLE
30A 86225190 75210
1 TANK,
SOLUTION
30B 86225220
75459
1 TANK, SOLUTION SPOTTER GRAY
31 86246180 51320 2 LATCH,
PRESTO
TANK
32
86006520
70052
4 SCREW, 8-32 X 3/8 PPHMS SS
33 86218160 35368 1 GASKET,
GROUND
WIRE
34
86247740
56049
1 NIPPLE, 1/4 X 6.0 BRASS
35
86227220
04066
1 ADPTR, 1/8 MPT X 1/4 FPT BRASS
36
86200820
270-11A
1 NIPPLE, 1/8 FPT QD MALE BRASS
37
86197580
40029
1 HOSEBARB, 1/4 MPT X 3/8
38
86197370
31017
1 ELBOW, 1/4 FPT X 1/4 FPT
39
86288450
70689
1 SCR, M4.8 X 10 HHTF TYPE B
40 86258310 140070 1 BULKHEAD,
UNION
41
86279320
87136
2 WASHER, .52 ID X .875 OD
42
86248090
59034
1 O-RING, .500 ID X .688 OD X .103
43
86007700
73250
1 STRAINER, 80 MESH X 3/8 FPT
44 86219010 39708 1 HOSE,
3/8
ID SGLBRD RBR X 5”
45 86233150 20042 2 CLAMP,
HOSE
46 86220140 500895 1
LABEL,
WARNING
47
86241790
48074
2 KEEPER, PRESTO LATCH
48
86236010
34290
1 FILTER, EMI 250V 6A 1.75MM
230V MACHINES ONLY
