M10 Nylon

Locknut (77)

M8 Washer (103)

M8 Nylon

Locknut (78)

M6 Washer

(114)

M4 Washer

(104)

M4 x 12mm

Self-tapping

Screw (102)

M4 x 16mm

Self-tapping
Screw (110)

M6 x 16mm

Screw (88)

M8 x 22mm

Shoulder Bolt (90)

M10 x 75mm Button Screw (118)

M10 Washer (80)

M10 Large Washer (105)

M12 Large Washer (98)

M10 x 100mm Bolt (140)

M12 Nut (112)

PART IDENTIFICATION CHART—

Model No. 831.14623.0

R0606A

Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST on pages 39 and 40.

Note: Some small parts may have

been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached. If a part is
missing, call toll-free 1-877-992-5999.
