MODEL 2411
SECTIONAL DOOR SYSTEMS
www. wayne-dalton .com/commercial
TheWayne-Dalton 2411 Steel Sectional Door is
designed to provide commercial strength at a
very competitive price.The embossed exterior
skin features a stucco finish to enhance the
building’s appearance, while “C”-shaped vertical
stiles on the door’s interior provide added
strength and allow quick, secure hinge
attachment. End stiles wrap around the exterior
of each section to protect the section face from
wear caused by the door jambs.
Materials & Construction
Wayne-Dalton’s 2411 features nominal 24-gauge
ribbed steel sections with vertical stiles attached
to the interior. These 20-gauge stiles are
securely attached with No. 8 screws and
adhesive and have prelocated, extruded holes
for hinge attachment. The exterior ribbing
consists of two deep and four shallow ribs in
each section, making it ideal for moderate use.
The bottom section features a vinyl bulb-shaped
astragal, held by a roll-formed, hot-dipped
galvanized steel retainer.
Additional options include top head seal, joint
seals and jamb seals. Optional insulation,
consisting of 1 9 /
16
" expanded polystyrene and
covered with .015" minimum embossed
pre-painted white steel provides an R-value of
up to 7.64 and a U-value as low as 0.13. Lite
options include insulated or non-insulated
factory-installed vision lites or aluminum full-
view sections for maximum visibility.
Contact Wayne-Dalton for additional sizes and
colors.
Vision Lites allow for visibility while
maintaining security
Aluminum full view sections allow for maximum
natural light and visibility
Window Options
• Chain Hoist Operation
• Motor Operation
Operation Options
White Embossed
Stucco Finish
Brown Embossed
Stucco Finish
Color Options
• Broken Cable Devices
• Safety Edges
• Safety Photo Eyes
Safety Options
• High Cycle Spring (25K,50K,100K)
• 3"Track Option
• Solid Shafts
• PerimeterWeatherseal
• Insulation
Performance Options
• SpecialTrack Designs
• Mullions
Special Application Options
