52
ITEM PART DEScRIPTION NO.
NO. NO. REQ’D
ITEM PART DEScRIPTION NO.
NO. NO. REQ’D
Use only genuine Walker ® replacement parts. Effective Date 06-15-10
ALL-TERRAIN TIRE KIT & TIRE cHAIN SETS
AT8072 All-Terrain Tire Option
Includes Item # 1 and instructions. May be ordered as a dealer-
installed option. Contact your Walker dealer.
1 8070-6 AT Wheel & Tire RH/LH (18 x 11-10) 2
8070-7 AT Tire RH/LH (18 x 11-10) *
8070-8 AT/LP Wheel (10 x 8.5) *
8075-2 AT/LP Tire Tube (18 x 11-10) *
2 8070-31 Wheel Spacer Plate (1/2) 2
Optional Tire chain Set
3 5675-3 Tire Chain Set (18 x 9.50-8) 1
Fasteners
F157 1/2-20 x 1-1/4 Wheel Lug Bolt 8
* Service Part Only
NOTE: Reuse Item # F157 from Wheel & Tire Assembly. Refer to
BODY / cHASSIS ASSEMBLY (GHS MODELS), Page 4.
