Base - motor – Windsor ROMBUS RMBS12 User Manual
Page 17
BASE - MOTOR
ROMBUS 980124 11/19/04
5-4
REF PART
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 01042 8
BUTTON
SCREWS
2A
01026
1
RMBS12 MCHN COVER
RMBS12 ONLY
2B
01037
1
RMBS16 MCHN COVER
RMBS16 ONLY
3 01070 1
CABLE
10M
4
01069
1
MOTOR CABLE 1M
5 01076 1
CABLE
GLAND
6 01068 1
SWITCH
LOCKING
NUT
7 01067 1
SWITCH
8 01054 3
SCREW
9 01063 1
END
HOUSING
10 01071 2
SCREW
11
01062
1
THERMAL RESET SWITCH COVER
12
01061
1
THERMAL RESET SWITCH
13A
01030
2
RMBS12 DRAW BARS
RMBS12 ONLY
13B
01041
2
RMBS16 DRAW BARS
RMBS16 ONLY
14A
01024
1
RMBS12 MTR SUPPORT – SWITCH END
RMBS12 ONLY
14B
01035
1
RMBS16 MTR SUPPORT – SWITCH END
RMBS16 ONLY
15A
01027
1
RMBS12 MOTOR
RMBS12 ONLY
15B
01038
1
RMBS16 MOTOR
RMBS16 ONLY
16 01075 2
CAPACITOR
SUPPORT
17 01079 2
CABLE
TIES
18 01053 1
CAPACITOR,
RUN
19 01044 1
BEARING
(MOTOR)
20 01043 1
CIRCLIP,
14MM
21A
01025
1
RMBS12 MTR SUPPORT – FAN END
RMBS12 ONLY
21B
01036
1
RMBS16 MTR SUPPORT – FAN END
RMBS16 ONLY
22 01045 1
CAPACITOR,
START
23
01064
1
END HOUSING, GEAR
24 01046 4
WASHERS
25 01078 2
NUT
26 01051 2
BEARING,
AXLE
27 01072 2
CIRCLIP,
15MM
28 01077 2
BEARING
29 01047 1
GEAR
30 01049 1
GEAR
31 01052 2
BEARING
32 01073 2
CIRCLIP,
11MM
33 01074 2
CIRCLIP,
35MM
34A
01048
1
GEAR
PIOR TO SN 16487
34B
01108
1
GEAR, 6F
16488
**SN 12125 – 12145
35 01050 1
GEAR
36 01055 2
CAP
SCREW
37 01057 2
CAP
SCREW
38
01099
1
END HOUSING GEAR COVER
