HANDLE
ROMBUS 980124 11/19/04
5-2
REF PART
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
RMH
1
RMBS HANDLE ASM CMPLT
2
01014
1
CABLE RESTRAINT
NOT SHOWN
3 01004 2
HANDLE
GRIPS
4 01008 2
CAP
PLUG
5 01009 1
CAP
SCREW
6
01007
1
UPPER CABLE HOLDER, LOCKED
7 01088 1
CAP
SCREW
8
01011
1
LWR CABLE HLDR, GYRATORY
9
01012
1
GYRATORY CBL RTNR SPRING
10 01013 1
BALL
BEARING
11
01021
2
NYLON, INSERT NUT
12 01018 2
HANDLE
BLOCKS
13 01017 1
5MM
PINS
14A
01097
1
RMBS12 HANDLE BAR (MCHN SD)
RMBS12 ONLY
14B
01098
1
RMBS16 HANDLE BAR (MCHN SD)
RMBS16 ONLY
15
01090
1
PIN, DOWEL M5
16 01019 2
M8
BOLT
17
01020
1
THUMB WHEELS & WASHER
18 01015 1
CARRY
HANDLES
19 01083 1
RMBS12/16
DECAL
20A
01093
1
SHAFT, LOCKING 12”
RMBS12 ONLY
20B
01094
1
SHAFT, LOCKING 16”
RMBS16 ONLY
21
01092
1
SCR, M10 SOCKET
22
01091
1
PIN, DOWEL M6
23 01089 1
SPRING,
24MM
24A 01095 1 BUSHING,
LOCKING 12”
RMBS12 ONLY
24B 01096 1 BUSHING,
LOCKING 16”
RMBS16 ONLY
25
01103
1
UPPER HANDLE BAR
26
01105
2
HANDLE CONNECTING BAR
27
01104
1
LOWER HANDLE SECTION
28
01106
8
SCR, M4 COUNTERSUNK
29
01107
8
WASHER, M4 S/S
NOT SHOWN
30
01109
1
ALLEN KEY
NOT SHOWN
