Vidikron PlasmaView Owner’s Operating Manual 5
PRE
L
IMINAR
Y
2.1
PlasmaView at a Glance
Controls and Indicators Figure 2-1 shows the PlasmaView front-panel controls and indicators.
Figure 2-1. PlasmaView Front-Panel Controls and Indicators
1. DISPLAY STAND
Optional accessory for table-top installations.
2. POWER BUTTON
Connects or disconnects the display panel from the AC power source.
3. STANDBY/ON INDICATOR
- Lights green to indicate normal operation;
- Lights red to indicate that the PlasmaView is in standby mode.
4. REMOTE CONTROL SENSOR
Receives the signals from the remote control.
2
Controls and Functions
1
3
2 4
