Chapter 1 Chapter 1 Chapter 1 Chapter 1 Basic Controls and Connections Basic Controls and Connections Basic Controls and Connections Basic Controls and Connections
1.1 1.1 1.1 1.1 Front Panel Front Panel Front Panel Front Panel
POWER ‘VIZIO’ LIGHT– The VIZIO name lights white
when powered on and orange when powered off.
REMOTE CONTROL SENSOR – This is the window
through which all of the remote control signals pass to
the sensor. Point the remote control directly at this
window for the best response to the remote signal.
1.2 1.2 1.2 1.2 Side Panel Controls Side Panel Controls Side Panel Controls Side Panel Controls
POWER ( ) – Switch the VU37L HDTV10A on by pressing
the button once. Press the button again to turn the VU37L
HDTV10A off.
MENU – This button activates the On Screen Display (OSD).
If a sub-menu is active, pressing this button will return to the
previous menu level.
CH + / - – Use these buttons to
step up or down the TV channels.
While the OSD is active, these
buttons function as up and down
controls in the OSD menus.
VOL + / - – Use these buttons to
increase or decrease to the
speaker volume. While the OSD is
active, these buttons function as
left and right controls in the OSD
menus.
INPUT (ENTER) – Repeated
pressing of this buttons steps
through the input sources in the
following sequence: TV, AV1/S-
Video, AV2, Component1, Component2, RGB, HDMI 1, HDMI 2 and HDMI 3. Once you have stepped
through the entire sequence, you will return to the beginning.
Additionally, when the OSD is active, this button confirms the menu function to be adjusted. When the
OSD is not active, pressing this button will display the current input mode.
