Installation and Replacement 3-15
Modifying Your Vanguard 3400 Series
Motherboard
Components Figure 3-8 shows the components on a Vanguard 3410 Series motherboard and
Figure 3-9 shows the components on a Vanguard 3460 Series motherboard.
Figure 3-8. Location of 3410 Motherboard Components
Battery
Daughtercard Slot 1 Encryption Module
Future Expansion Connection for Upgradeablity
Serial Number
Label
