Page 31
Hardware Description
2-5
Motherboard
Figure 2-5. Vanguard 3460 Series Motherboard
Accessing the
Motherboard
To access the motherboard components you must remove the motherboard from the
enclosure.
• For information about removing and installing the motherboard refer to the
“Accessing the Motherboard” section in Chapter 3.
• For information about removing or installing motherboard components, refer
to the “Modifying Your Vanguard 3400 Series” section in Chapter 3.
Battery
Daughtercard Slot 1
Encryption Module
Future Expansion Connection for Upgradeablity
Daughtercard Slot 2
Fan
Serial Number
Label
