Vizio CCU-11B User Manual

Page 6

5 DIP

SWITCH

FOR

FUNCTION SELECTION ON CCU-11B

The DIP switches on the CCU-11B allow selection of the following functions;

Switches

Functions

DIP-SW "ON "Position

DIP-SW "OFF "Position

Mini-Jumper for Battery

Battery "ON"

Position

Battery "OFF"

Position

OFF

Remote Control (Door)

Continues Calling Tone

OFF

Priority & Executive Priority

Press to Talk Control

Time Interval Adjustment
before All Call Paging Pre-
announce Tone

Calling Tone Duration

Call Transfer

All Call Paging & Response

Make/Break Relay Output

Activate

1 ~ 2 sec.

Short (0.7 sec)

Activate

One shot Relay Output

(4 sec.)

Not Activate

None

Long (1.3 sec)

Not Activate

Programming Switch

Station No. 11 is
"Programming station'

Station No. 11 is a
normal station

PROG

SW-B (SW1)

SW-A (SW2)

1: BATT. OFF

2: BATT. ON

OFF

A. All

Call

Paging

and

Response

B. Call Holding/Call Transfer

C. Calling

Tone

Duration

D. Time Interval Adjustment before All Call Paging

E. PTT

Control

F. Priority

and

Executive

Priority

G. Remote

Control

H. Continuous Calling Tone

— 5 —
