Component1, Display, Correctly – Vizio L42HDTV10A User Manual
Page 92
CONFIDENTIAL – DO NOT COPY
Page 9-3
File No. SG-0198
N0
N0
N0
N0
Yes
Yes
Yes
Yes
(COMPONENT1,
2)
IS
NOT
DISPLAY
CORRECTLY
Start
Input signal good?
1.Check video
2.Check host’s setting
P4 input correct?
1.Check signal between P4
2.Check power 12V& 5v
U11 input correct?
1.Check signal between U11&P4
2.Check U11 Clock (27MHZ)
LVDS output correct ?
1.Check U11
2.Check U11 power 3.3V&1.25v&1.8v
1.Is J5 connected good?
2.Is panel working ok?
END
