PINK BAG
GREEN BAG
HARDWARE INCLUDED
M5 x 10 Bolt
Quantity: 24
5.2 x 10 x 1.5
Flat Washer
Quantity: 24
5.1 x 9.3 x 1.3
Lock Washer
Quantity: 24
M8 x 62 Bolt
Quantity: 2
8.4 x 15.5 x 1.6
Flat Washer
Quantity: 4
M8 Nylon Nut
Quantity: 2
M10 x 123 Bolt
Quantity: 2
10.2 x 22 x 2
Flat Washer
Quantity: 4
M10 Nylon Nut
Quantity: 2
10.2 x 18.4 x 2.5
Lock Washer
Quantity: 8
M10 x 25 Bolt
Quantity: 8
20 x 30 x 1
Spacer/Teflon Washer
Quantity: 8
98mm Shaft (Z18)
illustration not to scale
Quantity: 2
105mm Shaft (Z19)
illustration not to scale
Quantity: 2
10 x 25 x 2
Flat Washer
Quantity: 8
