10
AC1 AC1
AG2 AG2
1
STEP
NOTE: During assembly, it is recommended
to ensure that all bolts are in place and
partially threaded before completely
tightening any one bolt. During assembly
steps 1 thru 4, do not completely tighten
any bolts until completion of Step 4.
• Lay the center floor support (AG2) flat
on the ground. Hold the main seat support
(AC1) upright and align the holes near the
pulley bracket with the holes on the center
floor support. Make sure the pulley bracket
on center floor support is on the opposite
side of the attachment. Secure connection
with two bolts (M10x120 & M10x25),
three flat washers (10.2x22x2), and a
nylon nut (M10).
ORANGE BAG
