AC1 AC1
AG2 AG2
AG1 AG1
AB1 AB1
11
2
STEP
• Attach two pulleys to the weight stack
tower (AB1) with two bolts (M10x48),
four flat washers (10.2x22x2), and two
nuts (M10).
• Stand the weight stack tower (AB1) so
that it is upright, and place it next to the
center floor support (AG2). Attach the
tower to the center floor support using two
bolts (M10x70), four flat washers
(10.2x22x2), and two nylon nuts (M10).
Attach the connecting brace (AG1) from
the weight stack tower to the main seat
support. On the weight stack side, use
two bolts (M10x60), four flat washers,
(10.2x22x2), and two nylon nuts (M10)
to secure. On other side of connecting
brace, use two bolts (M10x120), four flat
washers (10.2x22x2), and two nylon nuts
(M10) to secure.
BLUE BAG
