Vidikron Vision Model 120 Installation/Operation Manual
5
PRE
L
IMINAR
Y
2.1
Vision 120 at a Glance
Figure 2-1 shows the key Vision 120 components.
Figure 2-1. Vision 120 Front/Bottom/Side View
1.
PRIMARY PROJECTION LENS
2.
VIDIKRON LOGO
The logo can be rotated to match the projector orientation: inverted (ceiling-mounted)
or upright. To rotate the logo, grip it at the sides, pull it away from the projector and
rotate it 180 degrees.
3.
EXHAUST VENTS
2. Controls and Functions
3
1
3
2
