UNVENTED NATURAL GAS FIREPLACE
®
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
CORNER MANTEL
GM200F Series - Walnut Finished
GM201U Series - Unfinished
GM202F Series - Oak Finished
Shown with optional laminate mantel trim
accessory.
Dimensions (WxHxD): 60
7 /
8
" x 48 3 /
4
" x 34 5 /
8
"
ACCESSORIES
EQUIPMENT SHUTOFF
VALVE - GA5010
For all models. Equipment shutoff valve
with 1/8" NPT tap. Fits 1/2" NPT pipe.
SLIM HEARTH BASE
(Not Shown)
G3005J Series - Jade Marble
Laminate
G3005S Series - Sandstone
Marble Laminate
G3005B Series - Black Onyx
Marble Laminate
The slim hearth base allows you to further
customize your fireplace.
Dimensions (WxHxD): 41 7 /
8
" x 5/8" x 10"
Purchase these fireplace accessories from
your local dealer. If they can not supply
these accessories, call DESA International’s
Sales Department at 1-800-432-2382 for
information. You can also write to the ad-
dress listed on the back page of this manual.
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
,,,
,,,
,,,
QQQ
QQQ
QQQ
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
QQQQQQQQQQ
QQQQQQQQQQ
QQQQQQQQQQ
CABINET MANTEL
GM100F Series - Walnut Finished
GM101U Series - Unfinished
GM106F Series - Oak Finished with
Medium Stain
GM107U Series - Unfinished
GM102W Series - Off White Paint
Shown with optional base and laminate
hearth and mantel trim accessories.
Dimensions (WxHxD): 56 3 /
4
" x 48 3 /
4
" x 20 5 /
8
"
HARDWOOD HEARTH BASE
G3000F Series- Walnut Finished
G3001U Series - Unfinished
G3006F Series - Oak Finished
with Medium Stain
G3007U Series - Unfinished Oak
G3004W Series - Off White Finish
The hearth base can be used with the cabinet
mantels to create a handsome riser for the
fireplace (cannot be used with corner mantel).
Dimensions (WxHxD): 58" x 6 1 /
2
" x 28 9 /
16
"
BLOWER ACCESSORY
GA3700 SERIES AND
GA3700T SERIES
Manual variable control and automatic ther-
mostat variable control. A blower will in-
crease air flow to maximize heat distribution.
CORNER HEARTH BASE
G3008F Series - Walnut Finished
G3009U Series - Unfinished
G3010F Series - Oak Finished
The corner hearth base is designed for use
with the corner mantels to create a hand-
some riser for the fireplace.
Dimensions (WxHxD): 52
1 /
2
" x 6" x 23 3 /
4
"
