Main Unit
R 1142
CHIP RES.
150k
1/16W
5%
RMC1/16S 154JTH
J24189051
1-
B
c6
R 1143
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
c7
R 1144
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041
1-
B
b4
R 1145
CHIP RES.
390k
1/16W
5%
RMC1/16S 394JTH
J24189056
1-
A
C2
R 1146
CHIP RES.
220k
1/16W
5%
RMC1/16S 224JTH
J24189053
1-
B
c7
R 1147
CHIP RES.
33k
1/16W
5%
RMC1/16S 333JTH
J24189043
1-
B
c7
R 1148
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
B
c7
R 1149
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
B
c7
R 1150
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041
1-
B
c6
R 1151
CHIP RES.
15k
1/16W
5%
RMC1/16S 153JTH
J24189039
1-
B
c6
R 1152
CHIP RES.
390k
1/16W
5%
RMC1/16S 394JTH
J24189056
1-
A
C2
R 1153
CHIP RES.
220
1/16W
5%
RMC1/16S 221JTH
J24189017
1-
B
a2
R 1154
CHIP RES.
330k
1/16W
5%
RMC1/16S 334JTH
J24189055
1-
A
C3
R 1155
CHIP RES.
18
1/16W
5%
RMC1/16S 180JTH
J24189004
1-
B
b4
R 1156
CHIP RES.
330k
1/16W
5%
RMC1/16S 334JTH
J24189055
1-
A
C3
R 1157
CHIP RES.
18
1/16W
5%
RMC1/16S 180JTH
J24189004
1-
B
b4
R 1158
CHIP RES.
1M
1/16W
5%
RMC1/16S 105JTH
J24189061
1-
A
B2
R 1159
CHIP RES.
470k
1/16W
5%
RMC1/16S 474JTH
J24189057
1-
A
C3
R 1160
CHIP RES.
18
1/16W
5%
RMC1/16S 180JTH
J24189004
1-
B
b4
R 1161
CHIP RES.
8.2k
1/16W
5%
RMC1/16S 822JTH
J24189036
1-7
B
b4
R 1161
CHIP RES.
8.2k
1/16W
5%
RMC1/16S 822JTH
J24189036 CS VERSION
8-
B
b4
R 1161
CHIP RES.
8.2k
1/16W
5%
RMC1/16S 822JTH
J24189036 VERSION A
8
B
b4
R 1161
CHIP RES.
6.8k
1/16W
5%
RMC1/16S 682JTH
J24189035 VERSION A
9-
B
b4
R 1161
CHIP RES.
8.2k
1/16W
5%
RMC1/16S 822JTH
J24189036 VERSION D
8-
B
b4
R 1161
CHIP RES.
12k
1/16W
5%
RMC1/16S 123JTH
J24189038 VERSION F
8-
B
b4
R 1162
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
A
B2
R 1163
CHIP RES.
33k
1/16W
5%
RMC1/16S 333JTH
J24189043
1-
A
B2
R 1164
CHIP RES.
470k
1/16W
5%
RMC1/16S 474JTH
J24189057
1-
A
C3
R 1165
CHIP RES.
82k
1/16W
5%
RMC1/16S 823JTH
J24189048
1-
B
b4
R 1166
CHIP RES.
330k
1/16W
5%
RMC1/16S 334JTH
J24189055
1-
A
C3
R 1168
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
b4
R 1169
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
b4
R 1170
CHIP RES.
330k
1/16W
5%
RMC1/16S 334JTH
J24189055
1-
A
C3
R 1171
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
b7
R 1172
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
b7
R 1173
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041
1-
B
b4
R 1174
CHIP RES.
330k
1/16W
5%
RMC1/16S 334JTH
J24189055
1-
A
C3
R 1175
CHIP RES.
560
1/16W
5%
RMC1/16S 561JTH
J24189022
1-
B
b4
R 1176
CHIP RES.
82k
1/16W
5%
RMC1/16S 823JTH
J24189048
1-
B
b4
R 1177
CHIP RES.
33k
1/16W
5%
RMC1/16S 333JTH
J24189043
1-
A
B2
R 1178
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
a3
R 1179
CHIP RES.
68k
1/16W
5%
RMC1/16S 683JTH
J24189047
1-
B
b4
R 1181
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
b2
R 1182
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
b4
R 1183
CHIP RES.
18k
1/16W
5%
RMC1/16S 183JTH
J24189040
1-
B
b4
R 1183
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041
3-6
B
b4
R 1183
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041 CS VERSION
7-
B
b4
R 1183
CHIP RES.
39k
1/16W
5%
RMC1/16S 393JTH
J24189044 VERSION A
7-
B
b4
R 1183
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041 VERSION D
7-
B
b4
R 1183
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041 VERSION F
8-
B
b4
R 1184
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
b4
R 1185
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
A
B3
R 1186
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
A
B3
R 1187
CHIP RES.
220
1/16W
5%
RMC1/16S 221JTH
J24189017
1-
B
b4
R 1190
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
A
A2
R 1191
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
A3
R 1192
CHIP RES.
12k
1/16W
5%
RMC1/16S 123JTH
J24189038
1-
B
b7
R 1193
CHIP RES.
330k
1/16W
5%
RMC1/16S 334JTH
J24189055
1-
A
B3
R 1194
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
A
A3
R 1195
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
A
B3
DESCRIPTION
VALUE
V/W
TOL.
VXSTD P/N
MFR’S DESIG
VERS.
REF.
LOT. SIDE LAY ADR
