ViewSonic CD4200
ENGLISH
PC INPUT PRESET TIMING TABLE
* The resolution and the frequencies are displayed on the screen may not exactly as same
as this list.
PC / Timing Table
No. Mode
Name
Resolution
H.Freq.
(KHz)
V.Freq.
(Hz)
H.
Polarity
V.
Polarity
Pixel
CLK
(MHz)
Hor.
Total
CLK No.
Hor.
Display
CLK No.
Hor. Bck
Porch
CLK No.
Hor. Syth
CLK No.
Vert.
Total
Line No.
Vert.
Display
Line No.
Vert. Bak
Porch
Line No.
Vert. Syc
Width
Line No.
1
VESA 72HZ
640*480
37.900
72.809
-
-
31.500 832 640 128
40
520
480
28
3
2
VGA 60HZ
640*480
31.469
59.941
-
-
25.175 800 640
48
96
525
480
33
2
3
SVGA 56HZ
800*600
35.16
56.25
+
+
36.0 1024
800 128
72
625
600
22
2
4
SVGA 60HZ
800*600
37.879
60.317
+
+
40.0 1056
800 88
128 628
600
23
4
5
XGA 60HZ
1024*768
48.363
60.004
-
-
65.0 1344
1024 160 136 806
768
29
6
6
US TEXT
70HZ
720*400
31.469
70.087
-
+
28.322 900 720
54
108
449
400
35
2
7
XGA(CVT)
60HZ
1280*768
47.396
59.995
+
-
68.25 1440
1280 80
32
790
768
12
7
8
WXGA(CVT)
60HZ
1360*768
47.368
59.959
+
-
72 1520
1360 80 32 790 768 15
5
