Connections, Before making connections: wiring diagram, Before making connections – VIEWSONIC CD4225 User Manual
Page 18: Wiring diagram
ViewSonic CD4225
16
Connections
Before making connections:
• First turn off the power of all the attached equipment and make connections.
• Refer to the user manual included with each separate piece of equipment.
Wiring Diagram
VCR
HD
DVD
PC or equipment with
digital interface
LCD monitor (second monitor)
* Cables are not supplied
