Setup

Speaker connection

Note:
1.Unplug the TV set and all connected components before connecting the speakers.
2.The illustration may be different depending on model.

Connect the speaker audio
cable to the external speaker
output jacks on the unit
matching the "+" and "-" ends
of the cable by color.

Power connection

Connecting the AC plug to the wall outlet as illustrated.

Note:

This product should be operated only from the type of power source indicated on the marking label.

Always unplug the AC cord from power outlet when not using for a long period of time.

Plug into AC outlet.

AC cord

Household
power outlet

（Black）

（Red）

（Right speaker）

（Left speaker）

（Red）

（Black）
