LCD Module Diagonal:
Pixel Pitch:
Resolution:
Color:
Brightness:
Contrast Ratio:
Response time:
View Angle:
52" / 132.0 cm
0.60 mm
1920 x 1080 dots
1.07 billion colors (depending on video card used)
700 cd/m2 (typ.)
4000:1 (typ.)
8
ms (typ. G to G)
Up and Down 178°, Left and Right 178° (typ.) @CR>10
Frequency Horizontal:
Vertical:
15.625 / 15.734, 31.5 - 91.1 kHz
50.0 / 58.0 - 85.0 Hz
Pixel Clock 13.5 -165.0 MHz 25.0 -165.0 MHz
Viewable Size 1152 x 648 mm / 45.35 x 25.5 inches
Input Signal
PC-Input: Video:
Sync:
Input-terminal:
VIDEO Input:
AUDIO Input:
RS-232C:
In:
Analog RGB Video: 0.7 Vp-p TMDS
Input impedance 75 ohm
Separate HV sync: TTL level (Pos./Neg.),Input Impedance 2.2K ohm
15 Pin Mini D-sub HDMI
Composite: 1.0 Vp-p
Input impedance 75ohm BNC and RCA-PINJACK-INPUT
Y/C Y: 1 Vp-p C: 0.286 Vp-p Input
Impedance 75 ohm S-TERMINAL-INPUT
Component: 1.0 / 0.7 Vp-p
Input Impedance 75 ohm BNC-INPUT
RCA PIN-JACK L/R INPUT x 2, STEREO Mini Jack INPUT x 1
9 Pin Mini D-sub
Analog RGB Video: 0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Pos./Neg.)
15 Pin Mini D-sub
BNC-OUTPUT x 1, Composite 1.0 Vp-p with 75 ohm terminated
RCA PIN-JACK L/R OUTPUT x 1, 0.15 Vrms with 47k ohm terminated
Internal Speaker 5 W + 5 W (8 ohm)
External Speaker Jack 7 W + 7 W (8 ohm)
9 Pin Mini D-sub
Resolutions Supported
640 x 480 at 60 Hz
800 x 600 at 60Hz
1024 x 768 at 60Hz
1280 x 720 at 60Hz
1280 x 768 at 60Hz
1360 x 768 at 60Hz
1600 x 1200 at 60 Hz
1900x1200 (reduced Blanking only)
1920 x 1080 at 60Hz*
* Recommended Resolution
NTSC,PAL,SECAM,4.43NTSC,PAL60 DVD:480i,480p, 576i,720p,1080i,1080p
Power Supply 4.0 – 2.0 A @100 - 240 V AC, 50 / 60 Hz
Power Consumption
Power Save:
Typically 235 W
Less than 1W (Power button off or main power switch off.
Operational Temperature:
Environment Humidity:
Landscape: 5 - 40 °C / 41-104 °F, Portrait : 5 - 35 °C / 41 - 95 °F
20 - 80 % (Without condensation)
Storage Temperature:
Environment Humidity:
-20 - 60 °C / -4 - 140 °F
10 - 90% (Without condensation)/90%-3.5%x(Temp-40°C) regarding over 40°C
Dimension Net without stand:
Net with stand:
Gross:
1209 mm (W) x 705.5 mm (H) x 123 mm (D) / 47.59" (W) x 27.77" (H) x 4.85" (D)
1209 mm (W) x 751 mm (H) x 405.1 mm (D) / 47.59" (W) x 29.57" (H) x 15.95" (D)
1400 mm (W) x 945 mm (H) x 270 mm (D) / 55.12" (W) x 40.41" (H) x 10.63" (D)
Weight Net without stand:
Net with stand:
Gross:
81.3 lbs / 36.5 kg
83.8 lbs / 38 kg
103.5 lbs / 44 kg
Wall mounting interface
8 Holes (400 mm pitches)
Optional Multi-purpose Fix Mount
Complied Regulatory and Guidelines
UL60950-1/C-UL/EN60950-1/FCC-A/EN55022-A/EN55024/EN61000-3-2/EN61000-3-3 /CE/
ICES003-B/NOM
Power Management Support VESA DPMS convention
Plug & Play VESA DDC2B, DDC/CI
Accessories
User's Manual, Power Cord, VGA Cable, Remote Controller, AAA Battery x 2, Clamper x 2
(To prevent from falling), Screw for Main switch cover x 2, Screw for CLAMPER x 2,
Main switch cover.
Note: Technical specifications are subject to change without notice.
Specifications
Specifications
Product Specifications Analog Input Digital Input
4 5
ViewSonic
CD5233
Output Signal
PC-Output: Video:
Sync:
Output-terminal:
VIDEO Output:
AUDIO Output:
Speaker Output:
RS-232C: Out:
