Model no. 14 15 16 17 18 19
Model name VESA
1024x
768
Dos/70
720x
400
Dos/85
720x
400
480p
720x
480
720p
1280x
720
1080i
1920x
1080
Horizontal dots 1024 720 720 720 1280 1920
Vertical lines 768 400 400 480(p) 720(p) 1080(i)
Pixel clock (mhz) 78.75 28.327 35.5 27.00 74.25 74.25
Horizontal freq(khz) 60.023 31.468 37.927 31.468 45.00 33.75
Sync. Polarity + - - - - -
A h.total (us)(pixels) 16.660
(1312)
900 936 31.7
(856)
22.222
(1648) (2200)
B h.sync (us)(pixels) 1.219
(96)
108 36 2.37
(64)
0.54
(40) (44)
C h.back porch(us)
(pixels)
2.235
(176)
54 144 2.07
(56)
3.636
(270) (192)
D h.active
(us)(pixels)
13.003
(1024) (720) (720)
26.67
(720)
17.24
(1280)
E h.front porch(us)
(pixels)
0.203
(16)
18 36
Vertical freq (hz) 75.029 70.077 85.039 60.0 60.00 30
Sync. Polarity + + + -
O v.total (ms)(lines) 13.328
(800)
449 446 16.644
(525)
16.667
(750) (562.5)
P v.sync
(ms)(lines)
0.050
(3)
2 3 0.190
(6.0)
0.111
(5.0) (5.0)
Q v.back porch (ms)
(lines)
0.466
(28)
34 42 0.951
(30)
0.444
(20) (15)
R v.active
(ms)(lines)
12.795
(768) (400) (400) (480) (720) (1080)
S v.front porch
(ms)(lines)
0.017
(1)
13 1 5
