Vivitek RP56HD21-A - Manual (Page 50)

Model no. 8 9 10 11 12 13
Model name VESA
800x600
VESA
800x600
VESA
800x600
VESA
800x600
VESA
1024x768
VESA
1024x768
Horizontal dots 800 800 800 800 1024 1024
Vertical lines 600 600 600 600 768 768
Pixel clock (mhz) 40.00 50.00 49.500 56.250 65.00 75.00
Horizontal freq (khz) 37.879 48.077 46.875 53.674 48.363 56.476
Sync. Polarity + + + + - -
A h.total (us)(pixels) 26.400
(1056)
20.800
(1040)
21.333
(1056)
18.631
(1048)
20.677
(1344)
17.707
(1328)
B h.sync
(us)(pixels)
3.2
(128)
2.400
(120)
1.616
(80)
1.138
(64)
2.092
(136)
1.813
(136)
C h.back porch(us)
(pixels)
2.20
(88)
1.280
(64)
3.232
(160)
2.702
(152)
2.462
(160)
1.920
(144)
D h.active
(us)(pixels)
20.000
(800)
16.000
(800)
16.162
(800)
14.222
(800)
15.754
(1024)
13.653
(1024)
E h.front porch(us)
(pixels)
1.000
(40)
1.120
(56)
0.323
(16)
0.569
(32)
0.369
(24)
0.320
(24)
Vertical freq (hz) 60.317 72.188 75.00 85.061 60 70.069
Sync. Polarity + + + + - -
O v.total (ms)(lines) 16.579
(628)
13.853
(666)
13.333
(625)
11.756
(631)
16.666
(806)
14.272
(806)
P v.sync
(ms)(lines)
0.106
(4)
0.125
(6)
0.064
(3)
0.056
(3)
0.124
(6)
0.106
(6)
Q v.back porch (ms)
(lines)
0.607
(23)
0.478
(23)
0.448
(21)
0.503
(27)
0.600
(29)
0.513
(29)
R v.active
(ms)(lines)
15.840
(600)
12.480
(600)
12.800
(600)
11.179
(600)
15.880
(768)
13.599
(768)
S v.front porch
(ms)(lines)
0.026
(1)
0.770
(37)
0.021
(1)
0.019
(1)
0.062
(3)
0.053
(3)
