Vantec eSATA PCI & PCI-E Card & CardBus User Manual
Page 14
5.5. Connecting Drives:
SATA/eSATA PCI Host Controller (UGT-ST300) / SATA/eSATA PCI-Express Host
Controller (UGT-ST400):
Internal SATA:
Connect SATA cable to the Internal SATA port on the card.
Connect the other end to the drive.
External SATA:
Connect eSATA cable to the External SATA port on the card.
Connect the other end to the drive or enclosure.
2-Port eSATA PCMCIA CardBus (UGT-ST350CB):
External SATA:
Connect eSATA cable to either External SATA port on the CardBus.
Connect the other end to the drive or enclosure.
Installation
12
