Vantec C128 - Manual

Easily Add 2 Serial Ports and 1 Parallel Port To Any Computer
All 3 Ports Uses 1 PCI Slot
Works With Various USB Devices-Scanners, Modems, Digital Cameras, PDA,
Printers and More...
Compliant with PCI Local Bus Specification, Revision 2.3
Supports 2 x UART Serial Ports
Add one IEEE 1284 Parallel Port on system
Easy Plug and Play
Automatically selects IRQ & I/O address
Built-in 16C450/550 compatible UART
On chip 256 byte FIFOs in transmit and receive path of each serial port
Serial data transfer rate up to 115200bps
Supports Standard Parallel Port (SPP), Enhanced Parallel (EPP) & Enhanced
Capability Port (ECP)
Parallel data transfer rate up to 1.5Mbytes/sec
The Vantec 2+1 SERIAL & PARALLEL PCI HOST CARD is the easiest way to add extra serial and parallel ports to any computer. Compliant
with PCI local bus specification rev. 2.3, this host card will allow you to plug in three different (2 serial and 1 parallel) devices to a computer
whether it be a scanner, modem, digital camera, PDA, printer, etc. Easy to use and easy to install, get your Vantec 2+1 SERIAL & PARALLEL
PCI HOST CARD today.
Model:
Interface:
Ports:
OS Support:
Dimension:
UGT-PC2S1P
PCI
2 x Internal Serial Ports (DB9 Male)
1 x External Parallel Port (DB25 Female)
Windows® 2000, XP/2003 32/64-bit, Vista 32/64-bit
142x120x18mm
Computer with an available PCI slot
Windows®2000, XP 32/64-bit, Vista 32/64-bit
Vantec 2+1 Serial & Parallel PCI Host Card, User's Manual, Driver CD, Low Profile Bracket
Add Serial and Parallel Ports to your
motherboard!
Introduction:
Specifiactions:
System Requirement
Package Contents
Send us an e-mail at: [email protected]
All Registered Trademarks Belong To Their Respective Companies Copyright © 2010 Vantec Thermal Technologies. All Rights Reserved.
www.vantecusa.com
2+1 Serial & Parallel
PCI Host Card
